Quick Details
-
After-sales Service Provided:
-
Online support, Field installation, commissioning and training, Video technical support, Overseas Call Centers, Return and Replacement, Shop warranty, Free spare parts, Field maintenance and repair service, Genius, Onsite Installation
-
Tank Volume:
-
3000 liters
-
车身尺寸:
-
5400*1980*2380mm
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
DALI
-
Horsepower:
-
102hp
-
Product name:
-
JAC 3000L Septic Fecal Sewage Suction Tank Truck
-
Tank material:
-
High strength carbon steel carbon steel
-
Wheelbase:
-
2800mm
-
Driving Type:
-
4X2
-
Engine power:
-
102hp
-
Tires:
-
6.50R16LT
-
Highest speed:
-
115km/h
-
Chassis brand:
-
JAC
-
Certificate:
-
CCC;ISO...
-
Warranty:
-
1 year
Quick Details
-
Condition:
-
New
-
Emission Standard:
-
EURO 3
-
Gross Vehicle Weight:
-
4395
-
After-sales Service Provided:
-
Online support, Field installation, commissioning and training, Video technical support, Overseas Call Centers, Return and Replacement, Shop warranty, Free spare parts, Field maintenance and repair service, Genius, Onsite Installation
-
Tank Volume:
-
3000 liters
-
车身尺寸:
-
5400*1980*2380mm
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
DALI
-
Horsepower:
-
102hp
-
Product name:
-
JAC 3000L Septic Fecal Sewage Suction Tank Truck
-
Tank material:
-
High strength carbon steel carbon steel
-
Wheelbase:
-
2800mm
-
Driving Type:
-
4X2
-
Engine power:
-
102hp
-
Tires:
-
6.50R16LT
-
Highest speed:
-
115km/h
-
Chassis brand:
-
JAC
-
Certificate:
-
CCC;ISO...
-
Warranty:
-
1 year
JAC 3000L Vacuum Pump Sewage Truck
The tank material is made of WISCO 5 mm high quality steel plate, the head is made of 5 mm steel plate (reinforced with "well" steel lining), the force collector, drive shaft, vacuum suction pump, water separator, oil and gas separator, rotary base, excrement valve, suction gun, clear water tank, fecal window, vacuum pressure gauge, pipe network system, etc.
Performance Description:
Fukuda small card star suction truck top suction tube can rotate 360 degrees, the time to fill the tank takes about 5 minutes, suction range 6-7 m. It has the function of self-priming and self-discharge, simple operation, long life, fast working speed, large capacity and convenient transportation. It is suitable for collecting and transporting liquid substances such as feces and biogas liquid.
Views of 3cbm JAC fecal suction truck
| Technical Parameters | |
| Overall | |
| Product name | Vacuum Pump Fecal Suction Truck |
| Overall dimension(LxWxH) | 5900×2000×2350(mm) |
| Total weight | 7000 kg |
| Rated payload | 3000 kg |
| Curb weight | 4000 kg |
| Maximum speed | 95 km/h |
| Passenger | Single row cabin,2passengers |
| Chassis | |
| Brand | JAC |
| Driving type | 4*2 left hand drive |
| Wheelbase | 3360 mm |
| Fuel type | Diesel |
| Front/Rear axle loading capacity | 2000/5000 kg |
| Front/Rear Track | 1415/1485(mm) |
| Front/Rear suspension | 1115/1420(mm) |
| Tyre model/quantity | 6.50R16/6+1 pcs |
| Approach/Departure Angle(°) | 15/16(°) |
| Leaf spring quantity | 4/6+7 |
| Engine | |
| Engine brand | Cu mins |
| Power(hp) | 80hp |
| Displacement | 3200ml |
| Emission standard | Euro3 |
| Vacuum suction system | |
| Tank capacity | 3000 liters |
| Suction depth | ≤8m |
| Time for full suction | ≤5min |
| Basic equipment | Vacuum pump, ball valve, 5 meter pipe, pressure meter, window for showing liquid level, cleaning system, hoist base, water and oil separator, anti-leaking valve, etc. |
| Optional equipment | Sprinkler, alarm for full suction, double pump, crane, scissor lift, etc. |
Welcome to contact me if you have any question any time!
We provide free training for all our clients, both online and live training for option. If you need, we can also send engineers to give training to your at your site.
--- Packing: Waxed or nude, or covered with tarpaulin package.
--- Shipping: small type can be shipped in 20"GP,40"GP,or 40"HQ, big type can be
shipped in bulk ship or RO-ROshipping, or according to your requirement.
