Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
JIAPU
-
Model Number:
-
JP-60
-
Voltage:
-
220V 50-60HZ
-
Dimension(L*W*H):
-
1250*650*1300MM
-
Weight:
-
100 KG
-
Core Components:
-
ultrasonic system
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Max Sewing Speed:
-
0-20M/minute
-
Max Sewing Thickness:
-
20MM
-
Roller Size:
-
Wide:23MM-60MM Diameter:50MM
-
Output Frequency:
-
20KHZ
-
non woven bag making machine manual:
-
non woven bag making machine manual
-
Bag Width (Max):
-
100-800mm
-
PLC:
-
PANASONC JAPAN
-
Touch screen:
-
Weinview TAIWAN
-
Bags Usage:
-
Dry Bread Bag
Quick Details
-
Machine Type:
-
Sewing Machine
-
Bag Type:
-
Shopping Bag
-
Material:
-
Non Woven Bag
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
JIAPU
-
Model Number:
-
JP-60
-
Voltage:
-
220V 50-60HZ
-
Dimension(L*W*H):
-
1250*650*1300MM
-
Weight:
-
100 KG
-
Core Components:
-
ultrasonic system
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Max Sewing Speed:
-
0-20M/minute
-
Max Sewing Thickness:
-
20MM
-
Roller Size:
-
Wide:23MM-60MM Diameter:50MM
-
Output Frequency:
-
20KHZ
-
non woven bag making machine manual:
-
non woven bag making machine manual
-
Bag Width (Max):
-
100-800mm
-
PLC:
-
PANASONC JAPAN
-
Touch screen:
-
Weinview TAIWAN
-
Bags Usage:
-
Dry Bread Bag
| Main Product | |||
|
|
|
|
Non woven bag making machine manual
Function
This machine can make laces, non woven fabric bag and non woven surgical gown by changing the different rollers(molds), sewing non woven material together, cutting non woven fabric into pieces.
Feature
1. The operations of side scraping and trimming
The side scrap in one side and side melting can be carried out at the same time. It makes the side smooth, no roughness and no coarse side.
2. Make holes
The holes with different patterns can be cut and the treatment of side melting can be carried out too.
3. Transfer printing
Two layers or multi-layers can be melted together. It is not necessary to use thread and needle. This process can replace sewing. Moreover the melted strength is excellent.
4. Cut Material
This machine can cut material for single piece or many pieces at one time. Moreover it can carry out the treatment of side melting. There is no coarse side.
5. Forming
At one time the process of cutting, hole brearking and patter printing can be carried out.
Customer feedback
Customer visit
Transaction record
Technical parameter
|
Power Source |
220V 50-60HZ |
||
|
Inout Power |
1500-2500W |
||
|
Output Frequency |
20KHZ |
||
|
Working Speed |
0-20M/minute |
||
|
Roller Size |
JP-50B |
Wide : 23MM Diameter : 50MM |
|
|
JP-60 |
Wide : 23MM-60MM Diameter : 50MM |
||
|
JP-100 |
Wide : 50MM-100MM Diameter : 50MM |
||
|
JP-200 |
Wide : 100MM-190MM Diameter : 50-80MM |
||
|
Roller Size |
Wide : 23MM-60MM Diameter : 50MM |
||
|
Dimension |
1250*650*1300MM |
||
|
Weight |
100KG |
||
