Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
NEWMAX
-
Model Number:
-
NM-2994HD
-
Operation System:
-
UCOS
-
Features:
-
OTHER
-
Keyboard:
-
button
-
item:
-
Combo Auto DVB-S2 decoder
-
Language:
-
Support Multi Languages
-
Support:
-
H.264 Decoder
-
Warranty:
-
13 Months
-
Certificates:
-
CE ROHS FCC
-
Color:
-
Black
-
OEM:
-
Suport
-
Type:
-
Digital
-
Certification:
-
ce
Quick Details
-
Processor Core:
-
8001
-
Support Resolution:
-
1920 x 1080
-
WiFi:
-
802.11n 2.4GHz
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
NEWMAX
-
Model Number:
-
NM-2994HD
-
Operation System:
-
UCOS
-
Features:
-
OTHER
-
Keyboard:
-
button
-
item:
-
Combo Auto DVB-S2 decoder
-
Language:
-
Support Multi Languages
-
Support:
-
H.264 Decoder
-
Warranty:
-
13 Months
-
Certificates:
-
CE ROHS FCC
-
Color:
-
Black
-
OEM:
-
Suport
-
Type:
-
Digital
-
Certification:
-
ce
Products Description
|
SECTION
|
ITEM
|
DESCRIPTION
|
|
PROCESSOR
|
CPU
|
Montage CS8001-S030
|
|
|
Flash Memory
|
4MB
|
|
|
DDR2
|
64MB
|
|
DVB-S/S2 TUNER
|
Input Frequency:
|
950 ~2150MHz
|
|
|
Input level:
|
-80--20dBm
|
|
|
Input impedance
|
75Ω
|
|
DVB-T/T2 Tuner Complian with EN 302 755 DVB-T, EN 300 744 DVB-T2 Standarts
|
Iinput Frequency Range
|
VHF 170 ~ 230MHZ,UHF 470~862MHz
|
|
|
IF Bandwidth
|
6MHz/ 7MHz/ 8MHz
|
|
|
Input Slignali Level
|
- 85dBm~- 20dBm
|
|
|
Input impedance
|
75Ω
|
|
|
RF Input Connector
|
IEC 61169-2 antenna female connector
|
|
DVB-C Tuner Complian with EN 300 429 DVB-C Standart
|
Input frequency Range
|
48MHz~ 1GHz
|
|
|
Guard interval
|
1/4,19/128,1/8,19/256,1/16,1/32,1/128
|
|
|
FEC Code rates
|
1/2,2/3,3/4,3/5,4/5,5/6
|
|
DEMODULATOR
|
OFDM
|
16QAM,32QM,64QAM,128QAM,256QAM
|
|
CHANNEL DECODING
|
Demodulation
|
QPSK, 8PSK, 16PSK
|
|
|
FEC mode
|
DVB-S:1/2, 2/3,3/4, 5/6.7/8
|
|
|
|
DVB-S2:. 1/2. 3/5. 2/3.3/4. 4/5, 5/6.8/9. 9/10 (QPSK) 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 (8PSK)
|
|
|
Symbol Rate
|
DVB-S:2.0~45 MS/s
|
|
|
Demodulation
|
QPSK. 8PSK. DVB-S2: 10-30 Mb/s (QPSK). 10-31Mb/s (8PSK)
|
|
DEMUL TIPLEXER
|
Standard
|
ISO/IEC 13818-1
|
|
|
Input Max. Bit Stream Rate
|
100Mbps(Seria)/12. 5MBps(Parallel)
|
|
VIDEO DECODING
|
Standard
|
ISO/IEC 13818-2, MPEC-2 MP@ML, MPEG4 AVC (MP L4.1)
|
|
|
Aspect Ratio
|
4:3, 16:9
|
|
|
Video Format
|
PAL-BI/NTSC-M/ PAL-N/ PAL-M
|
|
|
Video Resolution
|
1080P, 1080I,720P ,480P/576P ,480i/576i SD compatible
|
|
AUDIO DECODING
|
Standard
|
ISO/EC 13818-3
|
|
|
Decoding
|
MPEG-1 Layer I and Il, MPEG-2, MPEG-4 AAC
|
|
|
Output Mode
|
LPCM, RAW
|
|
|
Sampling Frequency
|
32, 44.1, 48KHz
|
|
|
Volume Level
|
24 L evels
|
|
AV OUTPUT
|
Video de-emphasis
|
CCIR REC 405-1, 625LINES
|
|
|
Video bandwidth
|
5.5MHz
|
|
|
Video output impedance
|
75Ω
|
|
|
Video output level
|
1.0Vp-p
|
|
|
Audio output
|
Stereo
|
|
|
Audio output frequency
|
20Hz- 20KHz
|
|
|
Audio output impedance
|
Low
|
|
|
Audio output level A
|
1.0Vrms±2dB into 10K.
|
|
AV OUTPUT
|
Panel Interface
|
● 1xAV (CVBS+R/L AUDIO) ●1x HDTV ● 1 x LNB IN ●2 x USB 2.0 Port
|
|
OTHERS
|
Power input Spec.
|
12V/1A DC IN Max.12W
|
