Quick Details
-
Brand Name:
-
Hbowa or OEM
-
Model Number:
-
P-12V
-
Battery Size:
-
prismatic
-
Place of Origin:
-
Jiangsu, China
-
Weight:
-
2-50kg
-
The charging ratio:
-
0.5C
-
The discharge rate:
-
0.5C/1C
-
Electric Energy:
-
1280 Wh
-
Product name:
-
Energy Storage Battery
-
Cycle life:
-
6000 Times
-
Warranty:
-
5 Years
-
OEM/ODM:
-
Accepatable
-
Keywords:
-
12v 24v Lifepo4 Battery
-
Usage:
-
Slolar Energy System
-
Nominal Voltage:
-
12.8/48/51.2Vdc
-
Nominal Capacity:
-
50Ah/100Ah/200Ah/300Ah/400Ah
-
Certification:
-
CE/RoHS/UN38.3/MSDS
-
battery cell type:
-
Lithium Ion/LiFePO4
Quick Details
-
Storage Type:
-
-25-60℃
-
Anode Material:
-
LFP
-
Application:
-
Home Appliances, BOATS, Golf Carts, Electric Bicycles/Scooters, electric vehicles, Electric Power Systems, Solar Energy Storage Systems, Electric Forklifts
-
Brand Name:
-
Hbowa or OEM
-
Model Number:
-
P-12V
-
Battery Size:
-
prismatic
-
Place of Origin:
-
Jiangsu, China
-
Weight:
-
2-50kg
-
The charging ratio:
-
0.5C
-
The discharge rate:
-
0.5C/1C
-
Electric Energy:
-
1280 Wh
-
Product name:
-
Energy Storage Battery
-
Cycle life:
-
6000 Times
-
Warranty:
-
5 Years
-
OEM/ODM:
-
Accepatable
-
Keywords:
-
12v 24v Lifepo4 Battery
-
Usage:
-
Slolar Energy System
-
Nominal Voltage:
-
12.8/48/51.2Vdc
-
Nominal Capacity:
-
50Ah/100Ah/200Ah/300Ah/400Ah
-
Certification:
-
CE/RoHS/UN38.3/MSDS
-
battery cell type:
-
Lithium Ion/LiFePO4
Product Paramenters
|
Lead Acid Replacement Battery
|
|
|
|
|
|
|
||||||
|
Model
|
12V50Ah
|
12V100Ah
|
12V150Ah
|
12V200Ah
|
24V100Ah
|
48V100Ah
|
||||||
|
Continuous Dischage Current
|
25A
|
50A
|
50A
|
100A
|
50A
|
50A
|
||||||
|
Peak Protection Current
|
50A
|
100A
|
100A
|
200A
|
100A
|
100A
|
||||||
|
Working Voltage
|
10-14.6V
|
|
|
|
20-29.2V
|
37.5-54.75V
|
||||||
|
Standard Voltage
|
12.8V
|
|
|
|
25.6V
|
48V
|
||||||
|
Continuous Work Current
|
25A
|
50A
|
50A
|
100A
|
50A
|
50A
|
||||||
|
Max Charge Voltage
|
14.6V
|
|
|
|
29.2V
|
54.75V
|
||||||
|
Suggested DoD Model
|
90%
|
|
|
|
|
|
||||||
|
Size(mm)
|
330*172*216
|
332*172*216
|
332*172*220
|
532*207*215
|
345*190*245
|
520*267*220
|
||||||
|
Humidity
|
≤80%
|
|
|
|
|
|
||||||
|
Cooling Type
|
Natural Cooling
|
|
|
|
|
|
||||||
|
IP
|
IP65
|
|
|
|
|
|
||||||
|
Useful Life
|
8-10 Years
|
|
|
|
|
|
||||||
|
Certificates
|
CE, FCC, UN 38.3, MSDS, Class 9
|
|
|
|
|
|
||||||
Product Description
12V lithium batteries can be used in a variety of applications, and the specific usage will depend on the application. However, there are some general guidelines for using 12V lithium batteries:
1. Charging: Before using a 12V lithium battery, it must be charged fully. Most 12V lithium batteries come with a charger, and it's important to use the correct charger for your specific battery.
2. Connection: Once the 12V lithium battery is charged, it can be connected to the device or system that it will power. Be sure to follow the manufacturer's instructions for connecting the battery to the device or system.
3. Monitoring: It's important to monitor the voltage and charge level of the 12V lithium battery regularly. Most batteries come with built-in battery management systems (BMS) that can monitor and protect the battery from overcharging, over-discharging, and overheating.
4. Storage: When not in use, 12V lithium batteries should be stored in a cool, dry place away from direct sunlight. It's also important to keep the battery charged at around 50% capacity during storage to prevent damage.
5. Disposal: 12V lithium batteries should be disposed of properly and in accordance with local regulations. Many cities have recycling programs for lithium batteries, and it's important to follow the proper disposal procedures to prevent environmental damage.
Overall, 12V lithium batteries are easy to use, but it's important to follow the manufacturer's instructions and take proper care to ensure safe and reliable operation.
The advantages of lithium iron phosphate (LiFePO4) batteries are:
1. High energy density: LiFePO4 batteries have a higher energy density than traditional lead-acid batteries and nickel-metal hydride batteries, making them more lightweight and suitable for applications that require high energy density such as mobile devices and electric vehicles.
2. Long cycle life: LiFePO4 batteries have a longer cycle life than other types of lithium-ion batteries, allowing for more charging and discharging cycles and reducing the need for battery replacements, saving costs.
3. Good safety performance: LiFePO4 batteries have higher thermal stability and lower spontaneous combustion risk, making them safer and more reliable than other types of lithium-ion batteries.
4. Fast charging: LiFePO4 batteries have a high charging efficiency and can be charged quickly, which is convenient and efficient.
5. Environmentally friendly: LiFePO4 batteries do not contain heavy metals or toxic substances, making them relatively environmentally friendly.
In summary, the advantages of LiFePO4 batteries include high energy density, long cycle life, good safety performance, fast charging, and environmental friendliness, making them widely used in various fields such as electric vehicles, energy storage systems, and mobile devices.
1. Charging: Before using a 12V lithium battery, it must be charged fully. Most 12V lithium batteries come with a charger, and it's important to use the correct charger for your specific battery.
2. Connection: Once the 12V lithium battery is charged, it can be connected to the device or system that it will power. Be sure to follow the manufacturer's instructions for connecting the battery to the device or system.
3. Monitoring: It's important to monitor the voltage and charge level of the 12V lithium battery regularly. Most batteries come with built-in battery management systems (BMS) that can monitor and protect the battery from overcharging, over-discharging, and overheating.
4. Storage: When not in use, 12V lithium batteries should be stored in a cool, dry place away from direct sunlight. It's also important to keep the battery charged at around 50% capacity during storage to prevent damage.
5. Disposal: 12V lithium batteries should be disposed of properly and in accordance with local regulations. Many cities have recycling programs for lithium batteries, and it's important to follow the proper disposal procedures to prevent environmental damage.
Overall, 12V lithium batteries are easy to use, but it's important to follow the manufacturer's instructions and take proper care to ensure safe and reliable operation.
The advantages of lithium iron phosphate (LiFePO4) batteries are:
1. High energy density: LiFePO4 batteries have a higher energy density than traditional lead-acid batteries and nickel-metal hydride batteries, making them more lightweight and suitable for applications that require high energy density such as mobile devices and electric vehicles.
2. Long cycle life: LiFePO4 batteries have a longer cycle life than other types of lithium-ion batteries, allowing for more charging and discharging cycles and reducing the need for battery replacements, saving costs.
3. Good safety performance: LiFePO4 batteries have higher thermal stability and lower spontaneous combustion risk, making them safer and more reliable than other types of lithium-ion batteries.
4. Fast charging: LiFePO4 batteries have a high charging efficiency and can be charged quickly, which is convenient and efficient.
5. Environmentally friendly: LiFePO4 batteries do not contain heavy metals or toxic substances, making them relatively environmentally friendly.
In summary, the advantages of LiFePO4 batteries include high energy density, long cycle life, good safety performance, fast charging, and environmental friendliness, making them widely used in various fields such as electric vehicles, energy storage systems, and mobile devices.
Packing & Delivery
1,
We usually use cartons for packing
2,
We also accept custom packaging
