Quick Details
-
Model Number:
-
GSN4-HV-4G
-
Material:
-
iron
-
Color:
-
black, Black
-
Power:
-
Power
-
Display Type:
-
Analog and Digital
-
Theory:
-
Temperature Controller
-
Power Rating:
-
Standby 20mA
-
material:
-
metal
-
Usage:
-
Industrial Control
-
Temperature Range:
-
-55 ~ 125 °C (+/- 0.5°C )
-
Type:
-
Room Temperature Thermostat
-
Humidity Range:
-
1 ~ 100%RH (+/- 1% )
Quick Details
-
Warranty:
-
2 years
-
Place of Origin:
-
Hong Kong S.A.R.
-
Brand Name:
-
EASEMIND
-
Model Number:
-
GSN4-HV-4G
-
Material:
-
iron
-
Color:
-
black, Black
-
Power:
-
Power
-
Display Type:
-
Analog and Digital
-
Theory:
-
Temperature Controller
-
Power Rating:
-
Standby 20mA
-
material:
-
metal
-
Usage:
-
Industrial Control
-
Temperature Range:
-
-55 ~ 125 °C (+/- 0.5°C )
-
Type:
-
Room Temperature Thermostat
-
Humidity Range:
-
1 ~ 100%RH (+/- 1% )
Indoor air humidity thermometer Precision tester wireless weather station lora sensors Temperature Humidity 4G Ethernet Data
GSN4-HV-4G
is featured with analog, pulse, digital channels.
It provides data logging and tranmission over 4G and Ethernet network.
detail
It is a Temperature and Humidity Data Logger with built-in module supporting worldwide 4G mobile network.
4G Ethernet Data Logger provides faster wireless connection in a more secure and reliable 4G mobile and Ethernet network.
Its built-in UPS feature providing user alert of AC power loss.
During power loss, operation is backed up by internal rechargeable battery.
Overview:
* 4 Temperature Sensors (max.)
* 1 Humidity Sensor
* 2 Analog Channels (max.)
* 3 Digital Inputs
* 3 Pulse Channels
* 2 Relay Outputs
* RS485 Data In
Its internal 4MB memory logs ~30000 data records, and expandable to 32GB with SD card.
Data can be uploaded to server as fast as 5 seconds interval, or 24 hours to save power.
Progammable data logging interval starts from 1 minute up to 24 hours.
|
Temperature Sensors |
4 Temperature Sensors (max.) |
Power Input |
9 ~ 15VDC |
|
Humidity Sensor |
1 Humidity Sensor |
Digital Channel |
Alarm Dry Contact |
|
Analog Channel |
2 Analog Channels (max.) |
Pulse Channel |
On/Off Switching |
|
Digital Inputs |
3 Digital Inputs |
Industrial Protocol |
Modbus |
|
Pulse Channels |
3 Pulse Channels |
Communication Protocol |
4G, Ethernet |
|
Relay Outputs |
2 Relay Outputs |
temperature range |
-55~125℃ |
|
modbus interface |
RS485 Interface |
Accuracy |
+/-0.5℃ |
|
modbus |
8 Modbus Data Registers |
Alarm Trigger |
Digital Alarm / AD Level High or Low / Power Loss |
|
Display Type |
Analog and Digital |
Signal Type |
4~20mA or 0~5VDC |
Features
1) Real Time 4G Data Upload
2) Integrated 16 bit MCU & Siemens 4G and Ethernet Module
3) Programmable data input type & alert hi/low
4) Programmable Data Upload Interval & Logging Interval
5) Easy setup via USB port by PC software
6) Remote Setup over 4G mobile network
7) RS485 Port support data capturing in Modbus protocol
8) Support Dynamic Domain Name or Fixed IP, and UDP/TCP protocol data transmission
9) Flexible AC/DC power with internal battery backup
Free Software:
[1] Setup software is bundled for routine configuration via USB port locally
[2] Centre software is also provided for receiving data over Internet via 4G mobile network.
[3] Smart Client Lite app (Windows, iPad, Android) is free for user friendly graphics data display
Applications
* water pipes network real time monitoring - water in and out temperature
* oil/gas pipes network, pump stations
* underground water level real time monitoring
* environmental monitoring system - wind/temperature/humidity/CO2/pressure
* remote Industrial equipment monitoring
* rural equipment monitoring e.g. power plant, antenna tower
* measuring equipment data capture and report via 4G mobile and Ethernet network
* food chain, storage, transport industry, building management
* agricultural, farming, laboratory, medical industry
