- Product Details
- {{item.text}}
Quick Details
-
Material:
-
PVDF
-
Rated Voltage:
-
25kv
-
Tensile Strength:
-
25MPA
-
Product name:
-
pvdf heat shrink tube
-
Brand:
-
Deem
-
Origin:
-
China
-
Tensile strength:
-
25 Mpa min
-
Operating temperature:
-
-65℃ ~260℃
-
Elongation at break:
-
300%
-
Flammability:
-
Flame retardent
-
Dielectric strength:
-
25kv/mm min
-
shrink ratio:
-
1.3:1
Quick Details
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
DEEM
-
Model Number:
-
DM-KY
-
Material:
-
PVDF
-
Rated Voltage:
-
25kv
-
Tensile Strength:
-
25MPA
-
Product name:
-
pvdf heat shrink tube
-
Brand:
-
Deem
-
Origin:
-
China
-
Tensile strength:
-
25 Mpa min
-
Operating temperature:
-
-65℃ ~260℃
-
Elongation at break:
-
300%
-
Flammability:
-
Flame retardent
-
Dielectric strength:
-
25kv/mm min
-
shrink ratio:
-
1.3:1
Technical Data
| Property | Test Method | Typical Data |
| Operating temperature | IEC 216 | -55°C to +150°C |
| Tensile strength | ASTM D 2671 | ≥30 MPa |
| Elongation at break | ASTM D 2671 | ≥150% |
| Elongation at break after aging | 180°C/168hrs | ≥ 100% |
| Heat shock | 250°C/4 hrs. | No cracking |
| Cold bend | -55°C/4 hrs. | No cracking |
| Flammability | VW-1 | Pass |
| Volume resistance | IEC 93 | ≥10 14 Ω.cm |
| Copper corrosion | 180°C/168hrs. | No corrosion |
| Copper stability | 180°C/168hrs. | No sign of degradation |
Dimensions
| size | As Supplied (mm) | After Recovery (mm) |
Tube
Shape * |
Standard
length m/spool |
|
|
DM-KY
Inch.(D) |
Inside Diameter
Min. (D) |
Inside Diameter
Max. (d) |
Wall Thickness
Nominal. (t) |
||
| 3/64 | 1.2 | 0.6 | 0.26 | 0 | 200 |
| 1/16 | 1.6 | 0.8 | 0.26 | 0 | 200 |
| 3/32 | 2.4 | 1.2 | 0.26 | 0 | 200 |
| 1/8 | 3.2 | 1.6 | 0.26 | 0 | 100 |
| 3/16 | 4.8 | 2.4 | 0.26 | 0 | 100 |
| 1/4 | 6.4 | 3.2 | 0.26 | 0 | 100 |
| 3/8 | 9.5 | 4.8 | 0.3 | - | 50 |
| 1/2 | 12.7 | 6.4 | 0.3 | - | 50 |
| 3/4 | 19.1 | 9.5 | 0.41 | - | 50 |
| 1 | 25.4 | 12.7 | 0.41 | - | 50 |
| 1 1/2 | 38.1 | 19.1 | 0.51 | - | 50 |
* Tube shape “o”: Round shape or Oval “-”: Flat shape
*Spools as standards. 1 m. or 1,22 m. sticks, special spool lengths or cut pieces available on request.
