Quick Details
-
Control System Brand:
-
Cypcut / Germany PA HI8000
-
Cutting Area:
-
length 6000mm; diameter 20- 200mm
-
Cutting Thickness:
-
0-25mm
-
Control Software:
-
Cypcut/ Germany PA HI8000
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Golden Laser
-
Weight (KG):
-
14000 KG
-
Model number:
-
P2060A
-
Laser power:
-
1000W 1500W 2000W 2500W 3000W 4000W 6000W
-
Laser head:
-
RAYTOOLS
-
Laser source:
-
nLIGHT/ IPG/ Raycus fiber laser resonator
-
Position speed:
-
95m/min
-
Position accuracy:
-
±0.03mm
-
Maximum positioning speed:
-
120r/min
-
Maximum acceleration:
-
1.5G
-
Load weight:
-
25kg/M
-
Power supply demand:
-
AC 380V 50/60Hz
Quick Details
-
Laser Type:
-
Fiber Laser
-
Cutting Speed:
-
adjustable
-
Cooling Mode:
-
WATER COOLING
-
Control System Brand:
-
Cypcut / Germany PA HI8000
-
Cutting Area:
-
length 6000mm; diameter 20- 200mm
-
Cutting Thickness:
-
0-25mm
-
Control Software:
-
Cypcut/ Germany PA HI8000
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Golden Laser
-
Weight (KG):
-
14000 KG
-
Model number:
-
P2060A
-
Laser power:
-
1000W 1500W 2000W 2500W 3000W 4000W 6000W
-
Laser head:
-
RAYTOOLS
-
Laser source:
-
nLIGHT/ IPG/ Raycus fiber laser resonator
-
Position speed:
-
95m/min
-
Position accuracy:
-
±0.03mm
-
Maximum positioning speed:
-
120r/min
-
Maximum acceleration:
-
1.5G
-
Load weight:
-
25kg/M
-
Power supply demand:
-
AC 380V 50/60Hz
| Model number | P2060A |
| X Y axis maximum position speed | 95m/min |
| X Y axis Repeat positioning accuracy | ±0.03mm |
| Rotary axis maximum positioning speed | 120r/min |
| Rotary axis repeat position accuracy | 6Arc division |
| Maximum acceleration | 1.5G |
| Pipe cutting types | Round, square, rectangular, elliptical,waist round, angle iron, channel steel, I-beam, shaped tube, etc. |
| Pipe diamerter range | 20mm-200mm |
| Processing maximum length | 6000mm |
| Automatic bundle loader | √ |
| Max loading bundle size | 800mm* 800mm* 600mm |
| Automatic collecting device | Optional configuration |
| Slag removal function | Optional configuration |
| Weld identification function | Optional configuration |
| Laser brand | nLGIHT/IPG/Raycus |
| Power supply demand | AC 380V 50/60Hz |
Application Industry:
Especially for structural steel, model board frame, furniture, medical device, car base,fitness equipment, oil exploration, display shelf, farm machinery, bridge, shipping, structure parts, etc.
Application Materials:
Stainless steel, carbon steel, aluminum, alloy, galvanized steel, copper, brass, titanium, iron, etc.
Application Types of Tubes:
Standard type (Closed type) Round tube, square tube, rectangular tube, elliptical tube, oval tube, D-type t ube, Tria ngle tube, etc.
Modular type (Non-closed type) Channel steel, U-steel, angle steel, T-type, H-type, lath steel, etc.
1. Integrated chuck
Chuck and machine bed integration, making the chuck rotate faster
2. Automatic focusing cutting head
When cutting any material, it is not necessary to adjust the focal length again, it is easy to operate, saves time, and realizes automatic cutting.
3.
Automatic Bundle Loader:
Automatic bundle loader saves labor and loading time, result in mass production purpose.
Round pipe, rectangular pipe, elliptical tube, oval tube, D-type tube, triangle tube can be fully automated loading without human intervention. Other shaped pipe can be semi-automatic feeding manually.
4 .
Welding seam recognition:
Avoid drilling holes in solder joints and damaging the stress of the pipe
5. New type floating support system
Without manual intervention, the pipe will not swing freely, and the support height can be automatically adjusted in real time according to the change of the pipe attitude.
