- Product Details
- {{item.text}}
Quick Details
-
Speaker's Desk:
-
27" Capacitive Touch Full HD Monitor
-
PC:
-
i3 4/500GB Win 10 Pro
-
Gooseneck Microphone:
-
Available
-
Color:
-
Gray
-
Tocuh Screen:
-
Multi Touch Capacitive
-
Height Adjustment:
-
Available with remote control
-
Front Screen:
-
22" Full HD
-
Annotation Software:
-
Available
-
CMS:
-
Available
Quick Details
-
Place of Origin:
-
Istanbul, Turkey
-
Brand Name:
-
I-Podium
-
Model Number:
-
DL27M-F
-
Speaker's Desk:
-
27" Capacitive Touch Full HD Monitor
-
PC:
-
i3 4/500GB Win 10 Pro
-
Gooseneck Microphone:
-
Available
-
Color:
-
Gray
-
Tocuh Screen:
-
Multi Touch Capacitive
-
Height Adjustment:
-
Available with remote control
-
Front Screen:
-
22" Full HD
-
Annotation Software:
-
Available
-
CMS:
-
Available
Product Description
| Main Specifications | |
| Speaker Screen | 27" Multi touch capacitive |
| Front Screen | 22" with built-in signage media player |
| Built-in PC for Speaker Screen | intel i3 4GB Ram, 120 GB SSD, Win 10 Embedded ioT |
| Microphone | 1 pcs 18" Gooseneck Condenser Microphone |
| Lifting Column | Available |
| Detailed Specifications | |
| Front Panel | 22" |
| Screen Specifications | |
| Resolution | 1920x1080 FHD |
| Brightness | 250 cd/m 2 |
| Aspect ratio | 16:9 |
| Panel Type | IPS |
| Front Panel Player | Built-in Digital Signage Media Player |
| Front Panel Content Management Software | Available |
| Lecturer Panel | 27" |
| Screen Specifications | |
| Resolution | 1920x1080 FHD |
| Brightness | 250 cd/m 2 |
| Panel Type | IPS |
| Aspect ratio | 16:9 |
| Touch Technology | Capacitive |
| Touch Points | 10 points |
| Lecturer Panel PC Specifications | |
| CPU | 4th Generation Intel Core i3 |
| RAM | 4 GB DDR4 |
| HDD | 120 GB SSD |
| Operating System | Windows Embedded 10 IoT |
| Microphone | |
| Length | 18" |
| No of microphone | 1 pcs |
| Output Connector | 3-way XLR (Male) |
| Microphone Type | Cardioid |
| Frequency Response | 50 -18 kHz |
| Sensitivity (at 1,000Hz) | -60dB ± 3dB |
| Impedance | 220Ω |
| Power ON indicator | LED |
| Power requirement | Phantom Power (48V) |
| Height Adjust Engine | |
| Movement | Vertical (Up/Down) |
| Control | By Buttons (Up/Down) |
| Speed | Max speed: 38 mm/s |
| Lifting strength | 700N |
| Locking System | Automatic Looking when engine not working |
| Engine Type | Electrical |
| Remote control | Available |
| Timer & Chronometer | |
| Screen size | 3,5" |
| Clock | Available |
| Timer | Available |
| Stopwatch | Available |
| Touch | Single touch |
| Inputs (on Speaker Panel) | |
| USB | USB 2.0 and USB 3.0 (for internal PC) |
| Height udjustment | up&down |
| Outputs (Bottom of Podium) | |
| HDMI | Available |
| Ethernet | Available |
| XLR for microphone | Available |
| USB | USB 2.0 (for internal PC) |
| Power | |
| Power Input | 230V 50Hz |
| Power Consumption | 450W (max) |
| Peripherals &other features | |
| Color | Grey (RAL 7047) |
| Packing | Wooden box export packing |
Packaging & Shipping
Wooden export packing
Delivery time: 1 week
Our Services
-
· Custom design multimedia podium
· Optional features
· Removing some features you may don't need in the standard models
