Shingled string welding process, beautiful and neat
Customizable size and power
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
15years
-
Brand Name:
-
MARS or OEM
-
Model Number:
-
MS
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
1640*992*40mm
-
Product name:
-
Sola Panel
-
Open-circuit voltage:
-
36V or 43.2V
-
Frame Color:
-
white or black
-
Application:
-
solar energy system home
-
Module efficiency:
-
22%
-
Certifications:
-
CE RoHS
-
Max Power Voltage:
-
17.2V-35.2V
-
Max.System Voltage:
-
1000V
-
Certificate:
-
ce rohs
Quick Details
-
Cell size:
-
210mmx210mm
-
Type:
-
PERC, Half Cell, Double-glass, All Black, HJT, BIPV, Overlapping
-
Panel Efficiency:
-
22%
-
Warranty:
-
15years
-
Brand Name:
-
MARS or OEM
-
Model Number:
-
MS
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
1640*992*40mm
-
Product name:
-
Sola Panel
-
Open-circuit voltage:
-
36V or 43.2V
-
Frame Color:
-
white or black
-
Application:
-
solar energy system home
-
Module efficiency:
-
22%
-
Certifications:
-
CE RoHS
-
Max Power Voltage:
-
17.2V-35.2V
-
Max.System Voltage:
-
1000V
-
Certificate:
-
ce rohs
|
Maximum power at STC（Pmax）
|
400W
|
405W
|
410W
|
415W
|
420W
|
|
Optimum operating voltage（Vmp）
|
37.78V
|
37.82V
|
38.31V
|
38.32V
|
38.44V
|
|
Optimum operating current（Imp）
|
10.59A
|
10.72A
|
10.71A
|
10.83A
|
10.93A
|
|
Open-circuit voltage（Voc）
|
43.50V
|
43.58V
|
43.61A
|
43.66V
|
43.68V
|
|
Short-circuit current（Isc）
|
11.33A
|
11.43A
|
11.44A
|
11.53A
|
11.54A
|
|
Short-circuit current temperature coefficient （0.065±0.015）%/℃
|
|
|
|
|
|
Open-circuit voltage temperature coefficient -（80±10）mV/℃
|
|
|
|
|
|
Peak power temperature coefficient -（0.5±0.05）%/℃
|
|
|
|
|
|
NOCT (Air 20℃; Sun 0.8kW/m wind 1m/s) 47±2℃
|
|
|
|
|
|
Operating temperature -40℃ to 85℃
|
|
|
|
|
|
Maximum system voltage 1000V DC
|
|
|
|
|
|
Power tolerance ±3%
|
|
|
|
|
* Easy Installation
* High Aesthetic Value
* Wind, High Temperature Resistant
* Great Power Performance Under Weak Light
* High Aesthetic Value
* Wind, High Temperature Resistant
* Great Power Performance Under Weak Light
