Quick Details
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
LOVSUN
-
Model Number:
-
HY VMII Series Off Grid
-
Input Voltage:
-
230v
-
Output Voltage:
-
230v
-
Output Current:
-
80A
-
Output Frequency:
-
50/60HZ
-
Size:
-
120*330*460MM
-
Certificate:
-
ce/tuv
-
Warranty:
-
5 YEARS
-
Weight:
-
10KG, 10kg
-
Product name:
-
off grid solar inverter
-
Application:
-
Home Solar Power System
-
Inverter type:
-
Off-grid Power Inverter
-
Battery Voltage:
-
24V/48V
-
MPPT voltage range:
-
120VDC~450VDC
-
Battery type:
-
Lead Acid \ Lithium \ Gel
-
Keyword:
-
Solar Energy Power Inverter
-
Display:
-
LCD Display
-
Protection:
-
IP65
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
93%
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
LOVSUN
-
Model Number:
-
HY VMII Series Off Grid
-
Input Voltage:
-
230v
-
Output Voltage:
-
230v
-
Output Current:
-
80A
-
Output Frequency:
-
50/60HZ
-
Size:
-
120*330*460MM
-
Certificate:
-
ce/tuv
-
Warranty:
-
5 YEARS
-
Weight:
-
10KG, 10kg
-
Product name:
-
off grid solar inverter
-
Application:
-
Home Solar Power System
-
Inverter type:
-
Off-grid Power Inverter
-
Battery Voltage:
-
24V/48V
-
MPPT voltage range:
-
120VDC~450VDC
-
Battery type:
-
Lead Acid \ Lithium \ Gel
-
Keyword:
-
Solar Energy Power Inverter
-
Display:
-
LCD Display
-
Protection:
-
IP65
Product Description
Technical Specification
|
Model
|
|
|
HY3222VMII
|
|
HY5032VMII
|
|||||
|
RATED POWER
|
|
|
3200VA/3200W
|
|
5000VA/5000W
|
|||||
|
|
|
|
|
|
|
|||||
|
INPUT
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|||||
|
Voltage
|
|
|
230 VAC
|
|
|
|||||
|
Selectable Voltage Range
|
|
|
170-280 VAC(For Personal Computers);
90-280 VAC(For Home Appliances
|
|
|
|||||
|
|
|
|
|
|
|
|||||
|
Frequency Range
|
|
|
50 Hz/60 Hz(Auto sensing)
|
|
|
|||||
|
OUTPUT
|
|
|
|
|
|
|||||
|
AC Voltage Regulation (Batt.Mode)
|
|
|
230 VAC±5%
|
|
|
|||||
|
Surge Power
|
|
|
6000VA
|
|
10000VA
|
|||||
|
Efficiency(Peak
|
|
|
90%~93%
|
|
|
|||||
|
|
|
|
|
|
|
|||||
|
Transfer Time
|
|
|
10 ms (For Personal Computers);
20 ms(For Home Appliances)
|
|
|
|||||
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|||||
|
Waveform
|
|
|
Pure sine wave
|
|
|
|||||
|
BATTERY
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|||||
|
Battery Voltage
|
|
|
24 VDC
|
|
48 VDC
|
|||||
|
Floating Charge Voltage
|
|
|
27 VDC
|
|
54 VDC
|
|||||
|
Overcharge Protection
|
|
|
32 VDC
|
|
63 VDC
|
|||||
|
SOLAR CHARGER &AC CHARGER
|
|
|
|
|
|
|||||
|
Max PV ay Oper tag
|
|
|
500VDC
|
|
500VDC
|
|||||
|
Max.PV Array Power
|
|
|
4000 W
|
|
4000 W
|
|||||
|
MPP Range @operating Voltage
|
|
|
120~450VDC
|
|
120~450VDC
|
|||||
|
Max.Solar Charge Current
|
|
|
80 A
|
|
80 A
|
|||||
|
Max.AC Charge Current
|
|
|
60 A
|
|
60 A
|
|||||
|
Max.Charge Current
|
|
|
80 A
|
|
80 A
|
|||||
|
PHYSICAL
|
|
|
|
|
|
|||||
|
Dimension,DxWxH(mm)
|
|
|
100x300x440
|
|
|
|||||
|
Net Weight (kgs)
|
|
|
9
|
|
10
|
|||||
|
Communication Interface
|
|
|
JSB/RS22
|
|
|
|||||
|
ENVIRONMENT
|
|
|
|
|
|
|||||
|
Humidity
|
|
|
5%to 95%Relative Humidity (Non-condensing)
|
|
|
|||||
|
Operating Temperature
|
|
|
-10°C to 50°C
|
|
|
|||||
|
Storage Temperature
|
|
|
-15°C to 60°C
|
|
|
|||||
|
|
|
|
|
|
|
|||||
