Quartz glass sheets are usually cut and ground from quartz glass, with a silicon dioxide content of over 99.99%. The hardness is Mohs level seven, with characteristics such as high temperature resistance, low coefficient of thermal expansion, heat shock resistance, and good electrical insulation performance.
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JINGRUN
-
Model Number:
-
JRQ-0051
-
Product Name:
-
Quartz Plate
-
Material:
-
99.99% Pure Quartz
-
Size:
-
Customer's Requirement
-
Soften Temperature:
-
1780°
-
Color:
-
Clear Quartz Pipe
-
Edges Treatment:
-
Fine Polished Edge,Rough Edges and customized
-
Package:
-
Wooden Box
-
Packing:
-
Safe Exported Cartons
Quick Details
-
Type:
-
Translucent Quartz Plate
-
Application:
-
Optical instrument & Inbdustry
-
Thickness:
-
0.55mm-50mm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JINGRUN
-
Model Number:
-
JRQ-0051
-
Product Name:
-
Quartz Plate
-
Material:
-
99.99% Pure Quartz
-
Size:
-
Customer's Requirement
-
Soften Temperature:
-
1780°
-
Color:
-
Clear Quartz Pipe
-
Edges Treatment:
-
Fine Polished Edge,Rough Edges and customized
-
Package:
-
Wooden Box
-
Packing:
-
Safe Exported Cartons
Product Description
Round Tpye
|
Diameter: 1mm-500mm; Thickness: 0.5mm-500mm.
|
Rectangle Tpye
|
Length: 5mm-2000mm; Thickes: 0-500m-100mm
|
Density
|
2.2g/cm3
|
Compressive strength
|
1100Mpa
|
Young's modulus
|
72000Mpa
|
Modulus of rigidity
|
31000Mpa
|
Mohs hardness
|
5.5~6.5
|
Transformation point
|
1280°C
|
Softening Point
|
1780°C
|
Annealing point
|
1250°C
|
Specific heat (20 ~ 350 °C)
|
670J/kg.°C
|
Thermal conductivity (20 °C)
|
1.4W/m.°C
|
Index of refraction
|
1.4585
|
Thermal processing temperature
|
1750~2050°C
|
Short-term working temperature
|
1300°C
|
Long-term working temperature
|
1100°C
|
Strain
|
1270 C Fused The Quartz Glass Brick
|
PPM grade
|
Controlled 10/20/100 PPM
|
Electrical Resistivity: 1000°C
|
1x106 Q. cm
|
Details Images
![](https://cdn.bestsuppliers.com/seo_products_img/qdjingrunglass/90862a9115d036b4a9867b6b916779d3.jpg!/rotate/180)
![](https://cdn.bestsuppliers.com/seo_products_img/qdjingrunglass/98ffb0f3ac153227b34e64b7deaf51a8.jpg!/rotate/180)
Product show
![](https://cdn.bestsuppliers.com/seo_products_img/qdjingrunglass/8e2c2fa71fb73c9fa1ffb71aed1a2ec6.jpg!/rotate/180)
Quartz glass
![](https://cdn.bestsuppliers.com/seo_products_img/qdjingrunglass/fb983e208cff3be8a2a31907e11ed190.jpg!/rotate/180)
Use Scenarios
