Quick Details
-
Place of Origin:
-
Shandong, China
-
Image:
-
Black or Blue
-
Weight:
-
48-80gsm
-
Color:
-
White, Yellow, Pink, Green, Blue
Quick Details
-
Paper Roll:
-
NO
-
Brand Name:
-
TRUEPRINT, SUREWIN
-
Model Number:
-
GJ NCR PAPER 151
-
Place of Origin:
-
Shandong, China
-
Image:
-
Black or Blue
-
Weight:
-
48-80gsm
-
Color:
-
White, Yellow, Pink, Green, Blue
Product Description
Brief Instruction:
Carbonless paper works in a fairly simple way. It consists of sheets of paper that are coated on the bottom and/or the top with or and/or a reactive. The back of the first sheet is coated with micro-encapsulated dye. The top of the middle sheet is coated with a clay that quickly reacts with the dye to form a permanent mark. The back of the middle sheet is also coated with the dye.
The lowermost sheet is coated on the top surface with the clay with no coating applied to the back side.When someone writes on the sheets, the pressure from the point of the writing instrument causes the micro-capsules to break and spill their dye. Since the capsules are so small, the print obtained is very accurate. Carbonless copy paper was also available in a self-contained version that had both the ink and the clay on the same side of the paper.
Product Paramenters
Detail Introduction:
Substance: CB 48- 80gsm; CFB 50-60gsm; CF 48-170gsm
Available sheet sizes:
610X950mm, 610X864mm, 700X100mm, 650X1000mm etc.
Available widths:
200-1800mm
Length: 5000-15,000m
Transfer image: black & blue
Delivery date: 30 to 40 days
Material: 100% wood pulp/mixed pulp
OEM: Available
Transfer image: black & blue
Delivery date: 30 to 40 days
Material: 100% wood pulp/mixed pulp
OEM: Available
Specifications
|
Brand
|
|
TRUEPRINT NCR PAPER
|
|
|
|||
|
Substance(gsm)
|
|
CB white or tinted:48,50,52,55,60
CFB white or tinted:50,52,55
CF white or tinted:48,50,52,55,60
|
|
|
|||
|
Color
|
|
White, Green, Pink, Yellow, Blue
|
|
|
|||
|
Basis Weight Variation
|
|
±5%
|
|
|
|||
|
Whiteness
|
|
≥85% with OBA
|
|
|
|||
|
Opacity
|
|
≥60%
|
|
|
|||
|
Paper Density
|
|
0.67~0.83 g/m3
|
|
|
|||
|
Caliper Variation (CD)
|
|
≤6um for basis weights 50g/m² or less;
≤8um for basis weights more than 50g/m²;
|
|
|
|||
|
Smoothness (both sides)
|
|
≥60s
|
|
|
|||
|
Imaging Sensitivity
|
|
E≥86%;D≥86%(3 ply prints)
|
|
|
|||
|
Chromatic deviation
|
|
≤2.0%(coated side for tinted grades)
|
|
|
|||
|
Curls
|
|
≤12mm
|
|
|
|||
|
Surface strength
(medium viscosity printing ink)
|
|
≥0.4m/s (printing side)
|
|
|
|||
|
Light resistance
(residua lE after 144hrs)
|
|
≥50%
|
|
|
|||
|
Friction resistance (E)
|
|
≤6%
|
|
|
|||
|
TSI(MD)
|
|
≥55N.m/g
|
|
|
|||
|
Moisture on delivery
|
|
≤8.0% CB and CFB in sheets;
6.0%~7.5% CB and CFB in rolls;
6.0%~8.0% CF
|
|
|
|||
