Quick Details
-
Brand Name:
-
HPRT
-
Voltage:
-
150 VA
-
Dimension(L*W*H):
-
printer:210.65*184*229.65mm
-
Weight:
-
8 KG
-
Power Supply:
-
Internal switching power supply module, I / P: AC90V-264V,
-
Software:
-
HPRT Format Designer
-
Certification:
-
CCC
-
Environmental Conditions:
-
Operation: 0 to 40 ° C @ humidity 10% to 90% non-condensing
-
Machine Weight:
-
Printer: less than 8 kg ;Controller: less than 5 kg
Quick Details
-
Automatic Grade:
-
Intermittent/Continuous
-
Application:
-
VFFS/HFFS packing machine
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
HPRT
-
Voltage:
-
150 VA
-
Dimension(L*W*H):
-
printer:210.65*184*229.65mm
-
Weight:
-
8 KG
-
Power Supply:
-
Internal switching power supply module, I / P: AC90V-264V,
-
Software:
-
HPRT Format Designer
-
Certification:
-
CCC
-
Environmental Conditions:
-
Operation: 0 to 40 ° C @ humidity 10% to 90% non-condensing
-
Machine Weight:
-
Printer: less than 8 kg ;Controller: less than 5 kg
What is TTO?
Thermal Transfer Overprinting (TTO) is a technology that creates messages in resolutions up to 203dpi 300 dpi by pushing a ribbon
into contact with a substrate using a printhead.
The printhead is made up of a series of miniature print elements under a ceramic coating and a layer on the thermal printer ribbon
is covered with a coloured wax and/or resin mixture. The mixture on the ribbon melts as small areas of it come into contact with
the elements that are heated, this transfers and adheres colour to the surface of the substrate as it moves under the printhead.
Thermal transfer printers, functional in either continuous or intermittent printing modes, can print at high-resolution print
quality and on fast moving production lines. They can print a series of messages, including pricing, date and time coding,
barcodes, QR codes, logos, ingredients’ lists or even marketing messages.
Customers who have recently purchased our tto printers.
Products Description
|
Structure
|
All-metal structure
|
|
Printing Method
|
Thermal Transfer Printing
|
|
Resolution
|
300dpi (12 dots/mm)
|
|
Printing Speed
|
40-600mm/s
|
|
Printing Width
|
53mm
|
|
Print Area
|
53mm * 75mm (Intermittent)
53mm * 100mm (Continous) |
|
CPU
|
32-bit RSIC
|
|
Flash Memory
|
8MB (minimun)
|
|
Dynamic Memory
|
16MB(minumum)
|
|
Real-time Clock Function
|
STD (Battery Lifespan: min 3 years)
|
|
Sensor
|
Ribbon Tension Detection
Thermal Head Position Detection Cover Open Detection TPH over Temperature Detection Ribbon Break Detection |
|
Soft Package Detection
|
Electromagnetic Induction or Synchronizer
|
|
Soft Package Material
|
PVDC, PET, PE, NY, CPP, OPP, BOPP, BOPET, BOPA, CPP, PE,VMPET, VMCPP and other films and composite films
|
|
Capacity for Ribbon Loading
|
1 "mandrel with a maximum length of 1100 meters
|
|
Ribbon Type
|
Type: Wax / Resin-based
width: 20 mm (0.79 ") to 55 mm (2.17") |
|
Ribbon Saving
|
Support interlaced, radial, multiple print signals, digital ribbon saving printing, ribbon back and other ribbon saving modes;
The minimum ribbon interval between two lines of printing is not more than 0.5mm |
|
Air Pressure Supply
|
Max. 6 bar/90 psl
|
|
Airflow Consumption
|
As low as 4 ml / print at 2.5 bar
|
|
Print Density Level
|
Level 31
|
|
USB Interface
|
STD, 1 port, type B connector, USB device 2.0
|
|
USB HOST
|
STD, 1USB disk connection port ;
USB Host 2.0, automatic detection and setting of connections |
|
Serial Port
|
STD 1 port, female D-SUB 9-pin connectorDefault 9600, 8/N/1, variable baud rate and format
|
|
Ethernet Interface
|
STD 1 port, RJ-45 connector, IEEE802.3 10/100BASE-T
|
|
Hardware Interface Port
|
Input: "Print Start" and a configurable input ;
Outputs: fault, warning and 2 configurable outputs |
|
Power Supply
|
Internal switching power supply module, I / P: AC90V-264V, 47/63 Hz; 150 VA
|
|
Software
|
HPRT Format Designer
|
|
Certification
|
CCC
|
|
Environmental Conditions
|
Operation: 0 to 40 ° C @ humidity 10% to 90% non-condensing
Storage: -40 to 60 ° C @ humidity 10% to 90% non-condensing |
|
Machine Dimension
|
Printer: height less than 190 mm, width less than 220 mm, depth less than 236 mm
Controller: height less than 170 mm, width less than 263 mm, depth less than 190 mm |
|
Machine Weight
|
Printer: less than 8 kg ;Controller: less than 5 kg
|
|
Warranty
|
Printer: 3 years ; Controller: 3 years ;
Thermal head: 6 months or 50 KM;Platen: 5 years |
Features:
• Cost saving
• Optimized operation
• Highly reliable
• Environment friendly
• Effective printing
• Optimized ribbon usage
Application
Packing-TTO Printer
