Quick Details
-
Power:
-
7.6KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
CNCMC
-
Maximum Digging Height:
-
2600mm
-
Maximum Digging Depth:
-
1650mm
-
Machine Weight:
-
1000 kg
-
Max Digging Radius:
-
2900mm
-
Rated Speed:
-
2.3km/h
-
Marketing Type:
-
Hot Product 2023
Quick Details
-
Operating Weight:
-
1 ton
-
Bucket capacity:
-
0.03m3
-
Engine Brand:
-
KOOP/B&S
-
Power:
-
7.6KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
CNCMC
-
Maximum Digging Height:
-
2600mm
-
Maximum Digging Depth:
-
1650mm
-
Machine Weight:
-
1000 kg
-
Max Digging Radius:
-
2900mm
-
Rated Speed:
-
2.3km/h
-
Marketing Type:
-
Hot Product 2023
Product Description
Specification
|
Performance parameters (model: TE13)
|
|
|
|
|||
|
Weight
|
1000kg
|
Power
|
7.0kw
|
|||
|
Bucket digging force
|
10.3kn
|
Engine model
|
KOOP 192F（EURO 5）
Briggs & Stratton(EPA 4)
|
|||
|
Gradeability
|
30°
|
Bucket capacity
|
0.03m³
|
|||
|
Dimension
|
|
|
|
|||
|
Transport length
|
2170mm
|
Walking speed
|
2.3km/h
|
|||
|
Chassis width
|
940mm
|
Track width
|
180mm
|
|||
|
Total track length
|
1250mm
|
Minimum ground clearance
|
385mm
|
|||
|
Scope of work
|
|
|
|
|||
|
Maximum digging depth
|
1650mm
|
Maximum digging height
|
2600mm
|
|||
|
Minimum radius of gyration
|
1550mm
|
Maximum ground excavation radius
|
2900mm
|
|||
|
Maximum unloading height
|
1850mm
|
Hydraulic system
|
Eaton
|
|||
|
Transport size
|
2170*940*2200mm
|
|
|
|||
1.Rotary throttle
2.LCD panel
3.Pedal breaking
4.LED handlamp
5.Upgrade throttle valve
6.No Tail
7.Track width adjustable
8.Cast steel swing boom
9.Reserve mounting holes for attachment
