- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
CJSE
-
Marketing Type:
-
New Product 2022
-
Dimension(L*W*H):
-
9914 x 2628 x 3288mm
-
Capacity:
-
5-200
-
Weight:
-
10635
-
Inner Material:
-
Q345R
-
Outer Material:
-
Q345R
-
Design Pressure(MPa):
-
1.77
-
Design Standard:
-
GB150/ASME
-
Working Temperature(℃):
-
-19 - 50 ℃
-
lpg tank type:
-
lpg gas tank for zimbabwe
-
LPG Tank Volume:
-
propane gas storage tank best price lpg gas tank for zimbabwe
-
Type:
-
Horzontal
-
color:
-
netural grey or silver
-
features of tank:
-
heat treatment/X-ray detecting etc
-
applications:
-
for lpg storage
-
Medium:
-
Liquefied Petroleum Gas Propane
-
Product Keywords:
-
lpg gas tank for zimbabwe, lpg storage tank
-
Other name:
-
Liquefied Petroleum Gas Tank,Propane Tank
-
Standard:
-
ASME/GB150 LPG Gas Tank for Zimbabwe
Quick Details
-
Volume (m³):
-
5-200
-
Max Working Pressure(MPa):
-
1.82
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
CJSE
-
Marketing Type:
-
New Product 2022
-
Dimension(L*W*H):
-
9914 x 2628 x 3288mm
-
Capacity:
-
5-200
-
Weight:
-
10635
-
Inner Material:
-
Q345R
-
Outer Material:
-
Q345R
-
Design Pressure(MPa):
-
1.77
-
Design Standard:
-
GB150/ASME
-
Working Temperature(℃):
-
-19 - 50 ℃
-
lpg tank type:
-
lpg gas tank for zimbabwe
-
LPG Tank Volume:
-
propane gas storage tank best price lpg gas tank for zimbabwe
-
Type:
-
Horzontal
-
color:
-
netural grey or silver
-
features of tank:
-
heat treatment/X-ray detecting etc
-
applications:
-
for lpg storage
-
Medium:
-
Liquefied Petroleum Gas Propane
-
Product Keywords:
-
lpg gas tank for zimbabwe, lpg storage tank
-
Other name:
-
Liquefied Petroleum Gas Tank,Propane Tank
-
Standard:
-
ASME/GB150 LPG Gas Tank for Zimbabwe
Specification
|
LPG Gas Tank Type
|
|
III
|
|
Capacity of LPG Tank
|
cbm
|
50
|
|
Orientation of LPG Tank
|
|
Horizontal Single Layer LPG TANK
|
|
Working Pressure
|
MPa
|
1.63
|
|
Design Pressure
|
MPa
|
1.77
|
|
Max.allowance working pressure
|
MPa
|
1.82
|
|
Working Temperature
|
℃
|
-19~50
|
|
Design Temperature
|
℃
|
-20/54
|
|
Medium of LPG Tank
|
|
LPG (Propane)
|
|
Density of Medium
|
kg/m3
|
560
|
|
Main Material
|
|
Q345R
|
|
Filling Ratio
|
|
0.9
|
|
Setting Pressure of Safety Valve
|
MPa
|
1.82
|
|
Design Life
|
|
20 Years
|
|
Heat Treatment
|
|
Post-weld heat treatment for LPG Tank
|
|
Hydrostatic test pressure
|
MPa
|
2.28
|
|
Air tightness test pressure
|
MPa
|
1.77
|
|
Design, Manufacturing and Inspection Standard
|
|
GB150/ASME for LPG TANK
|
