Quick Details
-
Brand Name:
-
GASHILI
-
Dimensions(L*W*H):
-
5890*1120*1520mm
-
Weight:
-
680 KG
-
Certification:
-
CE
-
Application:
-
Print Candles
-
Product name:
-
Automatic candle screen printing machine
-
Color:
-
Silver
-
Printing color:
-
Multi Color Optional
-
Printing speed:
-
8000pcs/hr
-
Printing type:
-
Automtic Screen Printing Machine
-
Max printing size:
-
Dimeter 3-20mm
-
Max. Printing length:
-
60-160mm
-
MOQ:
-
1 Set
-
Printing products:
-
birthday candles, crayons
Quick Details
-
Condition:
-
New
-
Color & Page:
-
Multicolor
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
GASHILI
-
Dimensions(L*W*H):
-
5890*1120*1520mm
-
Weight:
-
680 KG
-
Certification:
-
CE
-
Application:
-
Print Candles
-
Product name:
-
Automatic candle screen printing machine
-
Color:
-
Silver
-
Printing color:
-
Multi Color Optional
-
Printing speed:
-
8000pcs/hr
-
Printing type:
-
Automtic Screen Printing Machine
-
Max printing size:
-
Dimeter 3-20mm
-
Max. Printing length:
-
60-160mm
-
MOQ:
-
1 Set
-
Printing products:
-
birthday candles, crayons
Product Description
Fully automatic candle screen printing machine, which can do silk screen printing on rod-shaped candles such as birthday candles to realize the printing of the whole circle pattern.
The machine drying system is individually designed to achieve drying and ensure that the candle does not deform.
Suitable for pole wax, birthday candles, crayons.
Details Images
Machine Features
1. One-person operation, dual-track operation at the same time, stopping, wiping, and adding ink at any time, the printed parts in the oven will not melt or deform;
2. Equipped with a vacuum adsorption function module (optional), the positioning of the workpiece is more accurate and reliable, and it prevents the candle from sticking to the screen during printing;
3. High-speed printing, up to 8000 pieces/hour;
4. Two different types of workpieces or patterns can be printed at the same time;
5. With double squeegee design, the printing and ink covering actions are cleaner and more reliable
Technical Parameter
.
1. Diameter of printed matter: φ3～φ20 mm
2. Length of printed matter: 60～160 mm
3. Printing stroke: 20～80 mm
4. Printing speed: 8000 pcs/hr
5. Power source: 220V 50/60Hz 5.8kw
6. Machine weight: 680kg
7. Dimensions: 5890×1120×1520mm
