Quick Details
-
Brand Name:
-
Dark Energy
-
Model Number:
-
11B3-36502L-E01-0
-
Output Frequency:
-
47~63HZ
-
Brand:
-
Dark Energy
-
Application:
-
Ceiling Light
-
Type:
-
Non Isolated
-
Power:
-
18-36W
-
Efficiency:
-
>90%@230VAC Full Load
-
Power Factor:
-
>0.5@230VAC Full Load
-
Output Voltage:
-
120-150VDC
-
Working temperature:
-
--15℃~+65℃
-
Size:
-
46*25*19MM
-
Protections:
-
Short Circuit
Quick Details
-
Warranty(Year):
-
2-Year
-
Product Weight（kg）:
-
0.4
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Dark Energy
-
Model Number:
-
11B3-36502L-E01-0
-
Output Frequency:
-
47~63HZ
-
Brand:
-
Dark Energy
-
Application:
-
Ceiling Light
-
Type:
-
Non Isolated
-
Power:
-
18-36W
-
Efficiency:
-
>90%@230VAC Full Load
-
Power Factor:
-
>0.5@230VAC Full Load
-
Output Voltage:
-
120-150VDC
-
Working temperature:
-
--15℃~+65℃
-
Size:
-
46*25*19MM
-
Protections:
-
Short Circuit
Products Description
|
Input Characteristics
|
Input Voltage Range
|
200-240VAC 50/60Hz
|
|
|
Power Range
|
36-50W
|
|
|
Power Factor
|
≥0.5/220Vac Full Load
|
|
|
Efficiency
|
≥90%/220Vac Full Load
|
|
|
Flicker Free
|
YES
|
|
Output Characteristics
|
Rated DC Voltage
|
120-150VDC
|
|
|
No-load Voltage
|
/
|
|
|
Rated Current
|
250-290mA
|
|
|
Rated Power
|
36-50W
|
|
|
Start-up Delay Time
|
<1S
|
|
Protection
|
Short Circuit
|
YES
|
|
|
Open Circuit
|
YES
|
|
|
Surge Voltage Protection
|
/
|
|
Environment
|
Working Tem
|
--15℃～+65℃
|
|
|
Working Humidity
|
20-90%RH
|
|
Safety
|
Insulation Resistance
|
≥4.0MΩ
|
|
|
Voltage Resistance Test
|
/
|
