Quick Details
-
Market Segement:
-
Urban construction muck transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
12.5T
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Video technical support, Online support, Free spare parts
-
Brand Name:
-
Shacman
-
Place of Origin:
-
Shandong, China
-
Dimensions (L x W x H) (mm):
-
8.6*2.55*3.45m
-
Cargo Tank Dimension:
-
5.8*2.35*1.5m
-
Announcement model:
-
SX5250ZLJDB3842B
-
Wheelbase:
-
3975+1400mm
-
Engine:
-
Weichai WP12.375E50
-
Gearbox:
-
Fast 12JSD180T
-
Rear axle speed ratio:
-
5.262
-
Front track:
-
2036mm
-
Rear wheelbase:
-
1860/1860mm
-
Maximum horsepower:
-
375 horsepower
-
Maximum output power:
-
276kw
-
Maximum torque:
-
1800Nm
Quick Details
-
Condition:
-
Used
-
Horsepower:
-
351 - 450hp
-
Emission Standard:
-
Euro 2
-
Market Segement:
-
Urban construction muck transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
12.5T
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Video technical support, Online support, Free spare parts
-
Brand Name:
-
Shacman
-
Place of Origin:
-
Shandong, China
-
Dimensions (L x W x H) (mm):
-
8.6*2.55*3.45m
-
Cargo Tank Dimension:
-
5.8*2.35*1.5m
-
Announcement model:
-
SX5250ZLJDB3842B
-
Wheelbase:
-
3975+1400mm
-
Engine:
-
Weichai WP12.375E50
-
Gearbox:
-
Fast 12JSD180T
-
Rear axle speed ratio:
-
5.262
-
Front track:
-
2036mm
-
Rear wheelbase:
-
1860/1860mm
-
Maximum horsepower:
-
375 horsepower
-
Maximum output power:
-
276kw
-
Maximum torque:
-
1800Nm
Product Description
Whatsapp or Wechat:+8618953747865
Shacman Automobile’s lightweight Delong F3000 6×4 dump truck is based on the strong R&D capabilities of “National Enterprise Technology Center and Postdoctoral Research Workstation”, and cooperates with well-known European heavy truck design companies to select the new generation of high-strength lightweight materials in China. Patented technology is designed into a large-capacity, lighter tare top box. The whole vehicle has the characteristics of lightweight, economical and practical, high strength, etc., and is especially suitable for transporting large-capacity coal, sand and gravel materials on high-efficiency roads. It has three major advantages: lighter weight, higher transportation efficiency, and safety and reliability.
Details Images
Specification
|
Announcement model
|
SX5250ZLJDB3842B
|
|
|
Drive form
|
6*4
|
|
|
Wheelbase
|
3975+1400mm
|
|
|
Engine
|
Weichai WP12.375E50
|
|
|
Gearbox
|
Fast 12JSD180T
|
|
|
Rear axle speed ratio
|
5.262
|
|
|
Body size
|
8.6*2.55*3.45 meters
|
|
|
Front track
|
2036mm
|
|
|
Rear wheelbase
|
1860/1860mm
|
|
|
Vehicle weight
|
12.5 tons
|
|
|
Rated load
|
12.37 tons
|
|
|
Total mass
|
25 tons
|
|
|
Tonnage level
|
heavy truck
|
|
|
Approach angle
|
17 degrees
|
|
|
Departure angle
|
23 degrees
|
|
|
Engine
|
|
|
|
Engine model
|
Weichai WP12.375E50
|
|
|
Number of cylinders
|
6
|
|
|
Fuel type
|
diesel
|
|
|
Displacement
|
11.596L
|
|
|
Emission standard
|
National V
|
|
|
Maximum horsepower
|
375 horsepower
|
|
|
Maximum output power
|
276kw
|
|
|
Maximum torque
|
1800Nm
|
|
|
Maximum torque speed
|
1000-1400rpm
|
|
|
Rated speed
|
1900rpm
|
|
|
Engine form
|
in-line, water-cooled, six-cylinder, electronically controlled high pressure common rail SCR
|
|
|
Cargo parameters
|
|
|
|
Cargo parameters
|
5.8*2.35*1.5 meters
|
|
|
Cab parameters
|
|
|
|
Cab
|
Medium and long flat roof
|
|
|
Gearbox parameters
|
|
|
|
Gearbox model
|
Fast 12JSD180T
|
|
|
Forward gear
|
12
|
|
|
Number of reverse gears
|
2
|
|
|
Tire
|
|
|
|
Tire specifications
|
11.00R20, 12.00R20 16PR
|
|
|
Number of tires
|
10
|
|
|
Tank
|
|
|
|
Fuel tank material
|
aluminum alloy
|
|
|
Fuel tank/gas tank capacity
|
400L
|
|
|
Chassis parameters
|
|
|
|
Frame height
|
850×300(8+7)mm
|
|
|
Front axle description
|
MAN9.5T
|
|
|
Allowable front axle load
|
7000kg
|
|
|
Rear axle description
|
16T MAN two-stage cast bridge
|
|
|
Allowable load of rear axle
|
18000 (two-axle group) kg
|
|
|
Speed ratio
|
5.262
|
|
|
Suspension type (front/rear)
|
four main films + four riding
|
|
|
Number of springs
|
10/12
|
|
|
Clutch
|
Φ430
|
|
Recommend Products
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
We will provide video inspection before shipment, and we have a professional transportation team.
