Quick Details
-
Warranty:
-
25 Years, 25 Year Linear Power
-
Brand Name:
-
Longi
-
Model Number:
-
LR5-72HPH 540-560M
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278*1134*35mm
-
Product name:
-
Longi Solar Panels
-
Power:
-
540-560W
-
Cell Type:
-
Monocrystalline
-
No. of Cells:
-
144
-
Weight:
-
27.5 Kg
-
Frame:
-
Anodized Aluminium Alloy
-
Front Glass:
-
Single Glass,3.2mm Coated Tempered Glass
-
J-box:
-
IP 68 ,Three diodes
-
Output Cable:
-
+400,-200mm/±1400mm
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell
-
Panel Efficiency:
-
21.7%
-
Warranty:
-
25 Years, 25 Year Linear Power
-
Brand Name:
-
Longi
-
Model Number:
-
LR5-72HPH 540-560M
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278*1134*35mm
-
Product name:
-
Longi Solar Panels
-
Power:
-
540-560W
-
Cell Type:
-
Monocrystalline
-
No. of Cells:
-
144
-
Weight:
-
27.5 Kg
-
Frame:
-
Anodized Aluminium Alloy
-
Front Glass:
-
Single Glass,3.2mm Coated Tempered Glass
-
J-box:
-
IP 68 ,Three diodes
-
Output Cable:
-
+400,-200mm/±1400mm
Product Description
Our high-efficiency PV modules are widely used all over the world, from alpine grasslands to desert wastelands, and from ponds and vegetable beds to household dwellings.
**Suitable for ground power plants and distributed projects
**Advanced module technology delivers superior module efficiency
**
Excellent outdoor power generation performance
**
High module quality ensures long-term reliability
Specification
|
Module Type
|
LR5-72HPH 540M
|
LR5-72HPH 545M
|
LR5-72HPH 550M
|
LR5-72HPH 560M
|
|||
|
Module Efficiency
|
20.9%
|
21.1%
|
21.3%
|
21.7%
|
|||
|
Voltage Max Power
|
41.65V
|
41.8V
|
41.95V
|
42.25V
|
|||
|
Open Circuit Voltage
|
49.5V
|
49.65V
|
49.8V
|
50.1V
|
|||
|
Current Max Power
|
12.97A
|
13.04A
|
13.12A
|
13.26A
|
|||
|
Short Circuit Current
|
13.85A
|
13.92A
|
13.98A
|
14.10A
|
|||
|
Cell Type
|
P Type
|
|
|
|
|||
|
Dimension
|
2278*1134*35mm
|
|
|
|
|||
|
Weight
|
27.5kg
|
|
|
|
|||
|
Junction Box
|
IP68, three diodes
|
|
|
|
|||
|
Package
|
31pcs per pallet/155pcs per 20' GP / 620PCS per 40HQ
|
|
|
|
|||
|
Warranty
|
12 years warranty for materials and processing, 25 years warranty for extra linear power output
|
|
|
|
|||
Strict QC System
Project Cases
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
