Quick Details
-
Certification:
-
CE ISO9001:2008
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Rainbow
-
Weight (KG):
-
1200
-
Certification:
-
CE ISO9001:2008
1 Body frame is made of iron plate welding
2 Spare parts is make from casting
3 Inner parts is made of bearing steel
Products:
|
Model: RSH-5 |
Specification |
|
Max. Blank Dia..(mm) |
3mm |
|
Max. Blank Length (mm) |
27mm |
|
Stroke (mm) |
38mm |
|
Output Speed (pcs/min) |
100-120pcs/min |
|
Die dia. |
20mm |
|
Cut-off die dia. |
13.5mm |
|
Punch Die 1st |
18mm |
|
Punch Die 2nd |
18mm |
|
Main motor power |
1HP |
|
Oil pump power |
1/4HP |
|
Net Weight |
500kgs |
|
Model: RSH-10 |
Specification |
|
Max. Blank Dia..(mm) |
4mm |
|
Max. Blank Length (mm) |
40mm |
|
Stroke (mm) |
64mm |
|
Output Speed (pcs/min) |
120-180pcs/min |
|
Die dia. |
34.5mm |
|
Cut-off die dia. |
15mm |
|
Punch Die 1st |
24mm |
|
Punch Die 2nd |
20mm |
|
Main motor power |
2HP |
|
Oil pump power |
1/4HP |
|
Net Weight |
1100kgs |
|
Model: RSH-15 |
Specification |
|
Max. Blank Dia..(mm) |
6mm |
|
Max. Blank Length (mm) |
65mm |
|
Stroke (mm) |
92mm |
|
Output Speed (pcs/min) |
130-160pcs/min |
|
Die dia. |
34.5mm |
|
Cut-off die dia. |
19mm |
|
Punch Die 1st |
31mm |
|
Punch Die 2nd |
31mm |
|
Main motor power |
3HP |
|
Oil pump power |
1/4HP |
|
Net Weight |
1600kgs |
|
Model: RSH-25: |
Specification |
|
Max. Blank Dia.(mm) |
8 |
|
Max. Blank Length(mm) |
120 |
|
Die Dia. |
54 |
|
P unch Die(1st&2nd) |
38 |
|
Main motor |
7HP. |
|
Output Speed (pcs/min) |
80-100 |
|
Stroke mm |
154 |
Company profile
Our company comes from China National Machinery Import and Export Corp. Harbin branch. By many years market development and experience accumulation,now we have became the biggest Chinese fastener equipment dealer and turnkey consultants of fasteners manufacturing project for abroad customers.
We are supplying high quality and reliable machines for the entire fastener industry with our professional and timely after sale service,our main products include wire drawing machine,Bolt Maker, Nut Maker, Part Former, Heading Machine, Thread Rolling Machine and Mesh Belt Furnace.
With our business reputation and professionalism, our company has experienced a significant growth in business during the recent years and we invested in some fastener equipment manufacturers and built our own bolt maker,mesh belt furnace and zinc plating line factories.We do these factories' foreign market developing and have received highly praises from a lot of customers.
We have established reputation in countries such as India, US, Europe and Southeast Asia where we have core customer bases. Meanwhile, we are well respected by the domestic factories and the customers in the mechanical and electrical business.
