Quick Details
-
Brand Name:
-
3C-LINK
-
Model Number:
-
3CI-SFP0208GM
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Industrial Ethernet Switch
-
RJ45 port and speed:
-
8*10/100/1000M Base-TX
-
Fiber port and speed:
-
2*1000 Base-FX SFP
-
PoE Standard:
-
8 x IEEE 802.3af/ IEEE 802.3at PoE
-
Managment:
-
VLAN, QoS, SNMP, IGMP snooping
-
Mac address table:
-
8K
-
Protection grade:
-
IP40 aluminum case
-
Packet buffer:
-
4Mbits
-
Maximum packet length:
-
up to 1532Bytes
-
Brand name:
-
3C-LINK
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
10 port
-
Brand Name:
-
3C-LINK
-
Model Number:
-
3CI-SFP0208GM
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Industrial Ethernet Switch
-
RJ45 port and speed:
-
8*10/100/1000M Base-TX
-
Fiber port and speed:
-
2*1000 Base-FX SFP
-
PoE Standard:
-
8 x IEEE 802.3af/ IEEE 802.3at PoE
-
Managment:
-
VLAN, QoS, SNMP, IGMP snooping
-
Mac address table:
-
8K
-
Protection grade:
-
IP40 aluminum case
-
Packet buffer:
-
4Mbits
-
Maximum packet length:
-
up to 1532Bytes
-
Brand name:
-
3C-LINK
Product Description
Product Description
The 3CI-PSE0208GM series is a high performance 10 port, industrial, managed gigabit Ethernet switch with eight 10/100/1000M PoE
ports and two gigabit SFP ports. The eight PoE ports support IEEE802.3af/at standard. The switch supports Ethernet Ring Protection
Switching (ERPS) as well as STP/RSTP/MSTP. It also supports Web-based network management, VLAN, QoS, SNMP, IGMP snooping and other
network functions. LED indicators provide the connection status when using SFP option. Rugged design with IP40 enclosure and
industrial level 3 ESD protection makes it suitable for many applications such as Intelligent Transportation Systems, IP
surveillance and industrial networks. The product is available in either DIN rail or wall-mount configurations
ports and two gigabit SFP ports. The eight PoE ports support IEEE802.3af/at standard. The switch supports Ethernet Ring Protection
Switching (ERPS) as well as STP/RSTP/MSTP. It also supports Web-based network management, VLAN, QoS, SNMP, IGMP snooping and other
network functions. LED indicators provide the connection status when using SFP option. Rugged design with IP40 enclosure and
industrial level 3 ESD protection makes it suitable for many applications such as Intelligent Transportation Systems, IP
surveillance and industrial networks. The product is available in either DIN rail or wall-mount configurations
Product Features
8* 10/100/1000Base-T Ethernet ports (PoE) 2* 1000BASE-X SFP ports EPRS (typical recovery time \< 30ms with 250 connected units)
STP / RSTP / MSTP redundancy protocols and standards SNMPv1/v2c/v3 & RMON & Port base/802.1Q VLAN network management IGMP Snooping
multicast function WEB, Telnet, SSH, Console (CLI) open and close port, binding MAC and port 802.1x network access control 802.1Q
protocol, Isolate network flow Radius Centralized password management IEEE802.3af/at standard Overload current protection and
reverse polarity protection IP40 enclosure protection Unique DIN mount design makes mounting and removal simple Both PoE and
Non-PoE models are available
STP / RSTP / MSTP redundancy protocols and standards SNMPv1/v2c/v3 & RMON & Port base/802.1Q VLAN network management IGMP Snooping
multicast function WEB, Telnet, SSH, Console (CLI) open and close port, binding MAC and port 802.1x network access control 802.1Q
protocol, Isolate network flow Radius Centralized password management IEEE802.3af/at standard Overload current protection and
reverse polarity protection IP40 enclosure protection Unique DIN mount design makes mounting and removal simple Both PoE and
Non-PoE models are available
Applications
|
Ordering Information
|
|
|
|
|
||||
|
3CI-SFP0102G
|
2×10/100/1000Base-TX + 2×100/1000Base-FX SFP,DC 12~48V. Unmanaged
|
|
|
|
||||
|
3CI-SFP0208GM
|
8×10/100/1000Base-TX + 2×100/1000Base-FX SFP,DC 12~48V. Managed
|
|
|
|
||||
|
3CI-SFP0408GM
|
8×10/100/1000Base-TX + 4×100/1000Base-FX SFP,DC 12~48V. Managed
|
|
|
|
||||
|
3CI-SFP0808GM
|
8×10/100/1000Base-TX + 8×100/1000Base-FX SFP,DC 12~48V. Managed
|
|
|
|
||||
|
3CI-SFP0216GM
|
2×10/100/1000Base-TX + 16×100/1000Base-FX SFP,DC 12~48V. Managed
|
|
|
|
||||
|
3CI-SFP1212GM
|
12×10/100/1000Base-TX + 12×100/1000Base-FX SFP,DC 12~48V. Managed
|
|
|
|
||||
|
3CI-PSE0208GM
|
8×10/100/1000Base-TX POE + 2×100/1000Base-FX SFP,DC 48~56V. Managed
|
|
|
|
||||
|
3CI-PSE0208GM
|
8×10/100/1000Base-TX POE+ 2×100/1000Base-FX SFP,DC 48~56V. Managed
|
|
|
|
||||
|
3CI-PSE0208GM
|
8×10/100/1000Base-TX POE+ 2×100/1000Base-FX SFP,DC 48~56V.. Managed
|
|
|
|
||||
