- Product Details
- {{item.text}}
Quick Details
-
Invoicing:
-
by theoretical weight
-
Place of Origin:
-
Tianjin, China
-
Thickness:
-
6-16mm
-
Application:
-
Construction,handrail,windows, Construction,handrail,windows,machinery, telecome,curtain wall
-
Length:
-
as per customers request.
-
Flange Width:
-
100-900
-
Flange Thickness:
-
8-28mm
-
Web Width:
-
100-300mm
-
Web Thickness:
-
6-16mm
-
Brand Name:
-
Tianjin Muchang
-
Model Number:
-
100*100-900*300
-
Surface Treatment:
-
Galvanized, Painted, Oil
-
Product name:
-
H-Beam
-
Shape:
-
H-shape I-shape
-
Key words:
-
Hot Rolled Mild Steel Beam
-
Technical:
-
Hot Rolled Beam
-
MOQ:
-
10 Tons
-
Surface:
-
Natural Surface
Quick Details
-
Grade:
-
Q235B
-
Standard:
-
JIS
-
Tolerance:
-
±5%
-
Invoicing:
-
by theoretical weight
-
Place of Origin:
-
Tianjin, China
-
Thickness:
-
6-16mm
-
Application:
-
Construction,handrail,windows, Construction,handrail,windows,machinery, telecome,curtain wall
-
Length:
-
as per customers request.
-
Flange Width:
-
100-900
-
Flange Thickness:
-
8-28mm
-
Web Width:
-
100-300mm
-
Web Thickness:
-
6-16mm
-
Brand Name:
-
Tianjin Muchang
-
Model Number:
-
100*100-900*300
-
Surface Treatment:
-
Galvanized, Painted, Oil
-
Product name:
-
H-Beam
-
Shape:
-
H-shape I-shape
-
Key words:
-
Hot Rolled Mild Steel Beam
-
Technical:
-
Hot Rolled Beam
-
MOQ:
-
10 Tons
-
Surface:
-
Natural Surface
Products Description
|
Product Name
|
I Beam IPE &IPEAA
|
|
|
||
|
Standard
|
AISI, ASTM, BS, DIN, GB, JIS, etc
|
|
|
||
|
Grade
|
SS400 A36 Q235 Q345 S235JR ST37, etc
|
|
|
||
|
Technique
|
Hot rolled
|
|
|
||
|
Zinc coating
|
15-80um or 120-600g/m2
|
|
|
||
|
Surface Treatment
|
Galvanized, Painted, Oil
|
|
|
||
|
Application
|
Construction,handrail,windows,machinery, telecome,curtain wall
|
|
|
||
|
Brand
|
Tianjin Muchang
|
|
|
||
|
Payment
|
T/T, L/C
|
|
|
||
|
Delivery Time
|
In 20-30 after receipt advance or LC
|
|
|
||
|
Min Order
|
25 Mt (one 20/40ft FCL)
|
|
|
||
|
European Standard of IPE AND IPEAA
|
|
|
|
|
||||
|
Waist Height
|
Leg breadth (mm)
|
Waist thickness (mm)
|
Leg thickness (mm)
|
Theory weight (kg/m)
|
||||
|
(mm)
|
|
|
|
|
||||
|
IPEAA 80
|
46
|
3.2
|
4.2
|
4.95
|
||||
|
IPE 80
|
46
|
3.8
|
5.2
|
6
|
||||
|
IPEAA 100
|
55
|
3.6
|
4.5
|
6.72
|
||||
|
IPE 100
|
55
|
4.1
|
5.7
|
8.1
|
||||
|
IPEAA 120
|
64
|
3.8
|
4.8
|
8.36
|
||||
|
IPE 120
|
64
|
4.4
|
6.3
|
10.4
|
||||
|
IPEAA 140
|
73
|
3.8
|
5.2
|
10.05
|
||||
|
IPE 140
|
73
|
4.7
|
6.9
|
12.9
|
||||
|
IPEAA 160
|
82
|
4
|
5.6
|
12.31
|
||||
|
IPE 160
|
82
|
5
|
7.4
|
15.8
|
||||
|
IPEAA 180
|
91
|
4.3
|
6.5
|
15.4
|
||||
|
IPE 180
|
91
|
5.3
|
8
|
18.8
|
||||
|
IPEAA 200
|
100
|
4.5
|
6.7
|
18
|
||||
|
IPE 200
|
100
|
5.6
|
8.5
|
22.4
|
||||
|
IPE 220
|
110
|
5.9
|
9.2
|
26.2
|
||||
|
IPE 240
|
120
|
6.2
|
9.8
|
30.7
|
||||
|
IPE 270
|
135
|
6.6
|
10.2
|
36.1
|
||||
|
IPE 300
|
150
|
7.1
|
10.7
|
42.2
|
||||
|
IPE 330
|
160
|
7.5
|
11.5
|
49.1
|
||||
|
IPE 360
|
170
|
8
|
12.7
|
57.1
|
||||
|
IPE 400
|
180
|
8.6
|
13.5
|
66.3
|
||||
|
IPE 450
|
190
|
9.4
|
14.6
|
77.6
|
||||
|
IPE 500
|
200
|
10.2
|
16
|
90.7
|
||||
|
IPE 550
|
210
|
11.1
|
17.2
|
106
|
||||
|
IPE 600
|
220
|
12
|
19
|
122
|
||||
Equipment Display
Product Details
Quality Inspection
Our company attaches great importance to product quality and has a variety of testing equipment and a complete quality testing system, including color coating adhesion testing, zinc coating quantity testing, tensile yield and hardness testing. We test all aspects of our products to ensure that they are delivered to our customers after meeting their requirements.
Product packaging
Package：
3 layers of packing, inside is kraft paper, water plastic film is in the middle and ousideGI steel sheet to be covered by steel
strips with lock, with inner coil sleeve .
strips with lock, with inner coil sleeve .
Remarks：
Insurance is all risks and accept the third party test
Loading Port：
Tianjin /Qingdao /Shanghai
Support train, container, bulk cargo and other logistics
Logistics partner cooperation for many years, stable and reliable, trustworthy
Company Infomation
Tianjin Muchang Materials Imp.& Exp. Corp is a professional steel product supplier and exporter in China. We devoted to
introducing quality products to the world, benefiting people's life. The product include steel pipes, galvanized steel coil ,
galvalume steel coil, PPGI , corrugated steel sheet , profiled bar, We make effort to build a first class corporate in Chinese
steel import and export line.
introducing quality products to the world, benefiting people's life. The product include steel pipes, galvanized steel coil ,
galvalume steel coil, PPGI , corrugated steel sheet , profiled bar, We make effort to build a first class corporate in Chinese
steel import and export line.
Tianjin Muchang Materials adhere to the quality, efficiency, customer service. In last decade, with an experienced, dynamic and highly efficient sales team, Tianjin Muchang has served many steel consumers, and achieved the annual export amount of ten million. We have successfully exported our products to more than 30 countries in the Middle East, Central and South America, Africa, etc. We are grateful for your trust, and willing to learn what you need.
1.Corporate Mission:
Devote to introducing quality products to the world, benefiting people's life. We make every effort to build a first class
corporate in Chinese steel import and export line.
Devote to introducing quality products to the world, benefiting people's life. We make every effort to build a first class
corporate in Chinese steel import and export line.
2.Corporate Philosophy:
Integrity, Teamwork, Professionalism and Innovation
3.Corporate Values:
Go forward together with the era, Create values together with customers, Develop together with employees
Integrity, Teamwork, Professionalism and Innovation
3.Corporate Values:
Go forward together with the era, Create values together with customers, Develop together with employees
FAQ
Q1: Are you factory or trading company?
A: We are manufacturer, we welcome customers from all over the world to visit our factory.
Q2:Can you send samples?
Q2:Can you send samples?
A:Of course, we can send samples to all parts of the world, our samples are free, but customers need to bear the courier costs.
Q3:What product information do I need to provide?
A:You need to provide the grade, width, thickness,coating and the number of tons you need to purchase.
Q4:About product prices?
A:Prices vary from period to period due to cyclical changes in the price of raw materials.
Q5:How long does your delivery time take?
A:In general, our delivery time is within 7-45 days, and may be delayed if the demand is extremely large or special circumstances occur.
Q6:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed. Best quality is our principle all the time. We have 2 times quality test before delivery.
Q7:How to pack the products?
A:The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden
pallet. It can effectively protect products from corrosion during ocean transportation.
Q8:What are the shipping ports?
A:Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you can choose other ports according to your needs.
Q9:What is your working time?
A:In general, our online service time is Beijing time: 8:00-22:00, after 22:00, we will reply to
your inquiry during the next working day.
your inquiry during the next working day.
