Features

Compared with the traditional item, the wireless temperature and humidity recorder can meet the fast working speed.

The most important thing is that can achieve remote real-time monitoring in 24 hours of unattended environment.

Just put a receiver in the office, through the zigbee 2.4G wireless network and monitoring software in PC,

You can easily sit in the office to see and check the changes of temperature and humidity in each environment clearly,

Not only real-time monitoring, also can query history data,

When the temperature and humidity data exceed the MAX/MIN limit,  It would alarm automatically.

Zigbee wireless transmission 2.4G, Fast, stable, and Strong anti-interference of signal transmission.

Model list

Model list
Model	S400W-TH	S400W-EX	S400W-ET	S400W-DT	S400W-EK
Temperature Accuracy	±0.5℃  ( 0.3℃ optional )
Humidity Accuracy	±5%RH		/
Temperature Measurement Range	-20~+70℃	-40~+85℃			-100~+100℃
Humidity Range	0~100%RH		/
Sensor type	Internal temperaute humidity sensor	External temperaute humidity sensor	External single temperaute sensor	External dual temperaute sensor	External thermocouple sensor
Resolution	0.1°C / 0.1%RH		0.1°C
Automatic Record Capacity	8192 records
Power	1.5V AA battery*4 / DC9V - 12V adapter
Logging rate	2s to 24 hours
Dimensions	90mm * 87mm * 44mm
Standard Accessories	Battery, user manual, solftware

Products Pictures

HE2400 Wireless receiver Base Station

Receiving data from each S400 device wirelessly, then transfer to Server Computer wired

(Wireless to RJ45 wired)

1 One receiver base station can connect with S400W device MAX quantity is 32units,

when the S400W more than the Receiver's Max capacity, you could take one more .

2, Interface : Zigbee to RJ45, receive the wireless signal sent by the instruments,

then transfer data to PC server wired by built-in RJ45 interface,

3, IP address : Fixed IP

4, The wireless distance between HE2400 and instruments not more 50M,

to ensure the singal receving stablely. Over 50M, take one more reciver.

Optional External light and sound alarm

Zigbee wireless monitoring system solution Topology

Tomonitor software to monitor real time data

Toclients : The history data can be searched by the ToClient software.

The history data can be downloaded as BMP graph, EXCEL, PDF.

Applications
