Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
zz-motor
-
Model Number:
-
110BLF230-630
-
Torque:
-
9.6nm, 9.6N.m
-
Product name:
-
110BLF230-630
-
Rated Voltage:
-
310v
-
Diameter:
-
110mm
-
Weight:
-
9.5kg
-
Speed:
-
30000rpm
-
warranty:
-
one year
-
Key words:
-
Bldc
-
Application:
-
Industrial
-
Function:
-
Automatic Control
Quick Details
-
Speed(RPM):
-
3000rpm
-
Continuous Current(A):
-
13A
-
Efficiency:
-
IE 1
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
zz-motor
-
Model Number:
-
110BLF230-630
-
Torque:
-
9.6nm, 9.6N.m
-
Product name:
-
110BLF230-630
-
Rated Voltage:
-
310v
-
Diameter:
-
110mm
-
Weight:
-
9.5kg
-
Speed:
-
30000rpm
-
warranty:
-
one year
-
Key words:
-
Bldc
-
Application:
-
Industrial
-
Function:
-
Automatic Control
Product Description
电气性能 Electrical Performance
绕组方式 Winding Type 星形 Star
霍尔电位角度 Hall Effect angle 120
°
绝缘等级 Insulation Class B 级绝缘
工作环境温度 Ambient Temperature Range -20
℃
~+50
℃
绝缘电阻 Insulation Resistance 100M
Ω Min 500VC DC
介电强度 Dielectric Strength 700V AC 1 minute
Electrical Specifications
|
型号 Model
|
110BLF110-430
|
110BLF110-630
|
110BLF170-630
|
110BLF230-630
|
57BLY115-230
|
||||
|
极数 Number of poles
|
8
|
|
|
|
|
||||
|
相数 Number of phases
|
3
|
|
|
|
|
||||
|
额定电压 Nominal voltage VDC
|
48
|
310
|
310
|
310
|
24
|
||||
|
额定转速 Rated speed RPM
|
3000
|
|
|
|
|
||||
|
额定扭矩 Rated torque N-m
|
3.2
|
3.2
|
6.4
|
9.6
|
0.45
|
||||
|
额定电流 Rated Current Amps
|
28
|
4.1
|
8.2
|
13
|
8.6
|
||||
|
输出功率·output power watts
|
1000
|
1000
|
2000
|
3000
|
140
|
||||
|
峰值扭矩 Peak Torque N-m
|
10
|
10
|
20
|
30
|
1.35
|
||||
|
峰值电流 Peak Current Amps
|
84
|
13
|
25
|
39
|
25.8
|
||||
|
力矩常数 Torque constant N-m/A
|
0.12
|
0.79
|
0.79
|
0.74
|
0.063
|
||||
|
反电势常数 Back EMF V/k RPM
|
8.4
|
55
|
55
|
55
|
6.6
|
||||
|
转动惯量 Rotor inertia g.c㎡
|
3
|
3
|
6
|
6
|
230
|
||||
|
机身长度 Body length (L) mm
|
110
|
110
|
170
|
21.6
|
115
|
||||
|
重量 Mass kg
|
4.5
|
4.5
|
7
|
9.5
|
1.25
|
||||
