Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SiRON
-
Model Number:
-
H016(C')
-
Material::
-
Plastic
-
Contact structure:
-
1NO 1NC
-
Contact resistance:
-
≤50MΩ
-
Insulation resistance:
-
≥100MΩ
-
Dielectric strength:
-
3000V,AC50Hz
-
Operating limits:
-
(button) about 3MM
-
Operation type:
-
self-locking
-
Certification:
-
CCC RoHS
Quick Details
-
Protection Level:
-
IP40
-
Max. Current:
-
10A
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SiRON
-
Model Number:
-
H016(C')
-
Material::
-
Plastic
-
Contact structure:
-
1NO 1NC
-
Contact resistance:
-
≤50MΩ
-
Insulation resistance:
-
≥100MΩ
-
Dielectric strength:
-
3000V,AC50Hz
-
Operating limits:
-
(button) about 3MM
-
Operation type:
-
self-locking
-
Certification:
-
CCC RoHS
Features
* Heat-resistant, impact-resistant, light-weight mechanical switching force, long service life, stable and reliable;
* Normally open and normally closed contacts adopt separate insulation structure and sliding design
to protect circuit safety;
* The product cap is made of new material, anti-oxidation, beautiful, safe and durable;
* Normally open and normally closed contacts adopt separate insulation structure and sliding design
to protect circuit safety;
* The product cap is made of new material, anti-oxidation, beautiful, safe and durable;
Specification
|
Model
|
|
H016(C) series
|
|
|
Operation type
|
|
self-locking
|
|
|
The environment temperature
|
|
-25°C~+55°C (no freezing) There must be air circulation around the lighting switch body
|
|
|
Environment humidity
|
|
45~85%RH (No condensation)
|
|
|
Contact structure
|
|
1NO 1NC
|
|
|
Contact material
|
|
Silver, silver cadmium oxide, silver gold plating, 3μm thickness
|
|
|
Contact resistance
|
|
≤50MΩ
|
|
|
Insulation resistance
|
|
≥100MΩ
|
|
|
Vibration resistance
|
|
50Hz, amplitude about 1.0mm
|
|
|
Impact resistance
|
|
>10g
|
|
|
Dielectric strength
|
|
3000V,AC50Hz,
|
|
|
Mechanical life
|
|
Self-resetting button: 1 million times; self-locking button: 500,000
|
|
|
Electrical life
|
|
More than 50,000 times
|
|
|
Wiring
|
|
Threaded connection, maximum wire diameter: 2×1.52 Terminal tab: 6.3×0.82
|
|
|
Operating force
|
|
800gf~2200gf, depending on the number of switching elements
|
|
|
Operating limits
|
|
(button) about 3MM
|
|
|
Switch rating
|
Rated insulation voltage
|
AC600V
|
|
|
|
Heating current
|
10A
|
|
|
|
Rated voltage
|
24V
|
|
|
|
DC
|
10A
|
|
|
|
AC
|
AC P.F=0.7
|
|
|
LED lamp beads
|
Lamp bead types
|
Bidirectional LED lamp beads (AC and DC common)
|
|
|
|
The rated voltage
|
24V/220V
|
|
|
|
Rated current
|
about 20mA
|
|
|
|
life
|
40000 hours (reference value)
|
|
