Quick Details
-
Warranty:
-
25years
-
Brand Name:
-
zhouyang
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2094*1038*35MM
-
Product name:
-
Solar panel
-
Maximum Power(Pmax):
-
Mono 450W
-
Power Tolerance:
-
0/+5W
-
Open Circuit Voltage(Voc):
-
49.30V
-
Maximum system voltage(VDC):
-
1500V
-
Short Circuit Current(Isc):
-
11.60A
-
Max series Fuse Rating:
-
20A
-
Max Power Voltage(Vmp):
-
41.50V
-
Operating Temp:
-
-40~85℃
-
Package:
-
carton or pallet
-
Certificate:
-
CE
Quick Details
-
Cell size:
-
166mmx166mm
-
Type:
-
PERC, Half Cell, All Black
-
Panel Efficiency:
-
21.5%
-
Warranty:
-
25years
-
Brand Name:
-
zhouyang
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2094*1038*35MM
-
Product name:
-
Solar panel
-
Maximum Power(Pmax):
-
Mono 450W
-
Power Tolerance:
-
0/+5W
-
Open Circuit Voltage(Voc):
-
49.30V
-
Maximum system voltage(VDC):
-
1500V
-
Short Circuit Current(Isc):
-
11.60A
-
Max series Fuse Rating:
-
20A
-
Max Power Voltage(Vmp):
-
41.50V
-
Operating Temp:
-
-40~85℃
-
Package:
-
carton or pallet
-
Certificate:
-
CE
Product Description
Specification
|
Product name
|
Solar panel
|
Solar panel
|
Solar panel
|
|
Brand Name
|
ZhouYang
|
ZhouYang
|
ZhouYang
|
|
Maximum power
|
450W
|
550W
|
650W
|
|
Place of Origin
|
Jiangsu, China
|
Jiangsu, China
|
Jiangsu, China
|
|
Size
|
2094*1038*35MM
|
2279*1134*35MM
|
2384*1303*35MM
|
|
Working Voltage
|
41.5V
|
41.01V
|
37.4V
|
|
Working current
|
10.85A
|
13.4A
|
17.38A
|
|
Open circuit voltage
|
49.3V
|
49.53V
|
45.2V
|
|
Short circuit current
|
11.6A
|
14.2A
|
18.46A
|
|
Cell number
|
144
|
144
|
132
|
|
Panel Efficiency
|
21.50%
|
21.50%
|
21.60%
|
|
Net weight
|
20KG
|
27.5KG
|
33KG
|
|
Package
|
carton or pallet
|
carton or pallet
|
carton or pallet
|
|
Max.System Voltage
|
DC1500V
|
DC1500V
|
DC1500V
|
|
Design Life
|
25years
|
25years
|
25years
|
