Quick Details
-
Product Name:
-
Industri Robot AGV
-
Maximum load:
-
100kg
-
Usage:
-
Material handling
-
Rated speed:
-
10m/min-45m/min
-
Battery life:
-
6-8h
Quick Details
-
Warranty:
-
1 Year
-
Weight (KG):
-
150
-
Place of Origin:
-
Jiangsu, China
-
Product Name:
-
Industri Robot AGV
-
Maximum load:
-
100kg
-
Usage:
-
Material handling
-
Rated speed:
-
10m/min-45m/min
-
Battery life:
-
6-8h
Product Overview
Automatic Guided Vehicle
AGV (Automated Guided Vehicle) refers to a transport vehicle equipped with automatic guidance devices such as electromagnetic or optical, which can travel along a specified guidance path, and has safety protection and various transfer functions. AGV belongs to The category of Wheeled Mobile Robot (WMR - Wheeled Mobile Robot). In industrial applications, there is no need for a driver's truck, and the rechargeable battery is used as the power source. Generally, its travel route and behavior can be controlled by a computer, or its travel route can be set up by using an electromagnetic path-following system. The electromagnetic path is pasted on the floor, and the driverless vehicle follows the electromagnetic track. The message carries the transporter that moves and moves.
Product Model
|
Number
|
Item
|
Basic parameters
|
|
1
|
Dimensions
|
Customizable
|
|
2
|
Mode of delivery
|
Two-way roller docking type
|
|
3
|
Drive mode
|
Differential drive
|
|
4
|
Driving speed
|
10m/min~45m/min
|
|
5
|
Maximum load
|
100Kg (Customizable)
|
|
6
|
Battery capacity
|
Standard 40Ah lithium battery (Customizable)
|
|
7
|
Battery life
|
≤8h, charging times greater than 600 times
|
|
8
|
Walking function
|
Forward, Backward, Acceleration, Deceleration, Turning, Pause, Permanent stop, Fork choice
|
Advantages
The AGV trolley with auxiliary device completes the transportation between each station.
* Ground Navigation System
The ground navigation system is mainly composed of magnetic strips and RFID landmarks. The magnetic strips and RFID landmarks constitute the operation area of AGV, forming different paths for AGV operation.
* Automatic charging station
In order to ensure the reliability of AGV's continuous operation and use within 24 hours, the AGV automatically goes to the charging area to replenish energy when the voltage is low. The charging process of the AGV is carried out automatically under the monitoring of the dispatching system.
*Security system
When an obstacle is encountered in the detection area, the AGV automatically decelerates and stops moving forward; when encountering an obstacle in the emergency stop area, the trolley stops immediately, and the obstacle is eliminated and automatically continues to perform the task; other external stops and departures require external confirmation before starting operation.
* Communication system
The communication system consists of a wireless local area network between the dispatching system and each AGV, and the wireless local area network is used for information exchange between the AGV and the dispatching system.
