Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
xindali
-
Model Number:
-
LAY5-BA31
-
Operation type:
-
Push Spring Return
-
Material:
-
Metal Stainless Aluminum
-
Color:
-
Green
-
Voltage:
-
6v/12v/24/110v/220v/380v
-
Certification:
-
CQC CE ROHS ISO9001
Quick Details
-
Protection Level:
-
ip45
-
Max. Current:
-
10a
-
Max. Voltage:
-
220v
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
xindali
-
Model Number:
-
LAY5-BA31
-
Operation type:
-
Push Spring Return
-
Material:
-
Metal Stainless Aluminum
-
Color:
-
Green
-
Voltage:
-
6v/12v/24/110v/220v/380v
-
Certification:
-
CQC CE ROHS ISO9001
Product Description
Product Application
The push button series are used in controlling circuit of AC voltage up to 660V/AC50Hz or 60Hz,and DC voltgae below 400V.It is used for controlling signal and interlocking purposes.The main body of the push buttons adopts zinc alloy and high-grade anti-flam plastic.The contact adopts special silver alloy in order to enjoy the benefit of high anti-electrical erosion.The signal lamp series are suitable for electrical appliances circuit of AC voltage up to 380V/50Hz,and DC voltage below 380V.It is ideal for using as indicating signals,warning signal,emergency signal,etc.Our products comply with GB/T14048.1 and IEC60947-5-1,all prouducts are CE,IOS9001,ROHS and UL certified.
|
Main technical parameter
|
|
|
|
|
||||
|
Basic technical parameter of button
|
|
|
Basic technical parameter of signal lamp
|
|
||||
|
Rated insulation
|
AC 600V(50Hz/60Hz)
|
|
Insulation resistance
|
≥50MΩ
|
||||
|
Conventional heating current
|
10A
|
|
Contact resistance
|
≤25MinΩ
|
||||
|
Insulation resistance
|
≥50MΩ
|
|
Pf withstand voltage
|
AC 2.5KV/min
|
||||
|
Contact resistance
|
≤25MinΩ
|
|
Voltage wave
|
±20%
|
||||
|
Mechanical life
|
100x10000
pushbutton |
50x10000
selector switch |
Brightness
|
60cd/m2
|
||||
|
Electrical life
|
500x10000
pushbutton |
25x10000
Selector switch |
Continuous working life
|
10x10000h
|
||||
Main Features
1)Surrounding temperature:-25℃~+55℃
2) Air relative humidity:≤85%
3) It can be normally work under following condition:
Vibration frequency is 2~80Hz and acceleration speed is 0.7g/h:
4) Pollution grade is III,installation sort is III,protection grade is up to IP65.
2) Air relative humidity:≤85%
3) It can be normally work under following condition:
Vibration frequency is 2~80Hz and acceleration speed is 0.7g/h:
4) Pollution grade is III,installation sort is III,protection grade is up to IP65.
5) Altitude:≤2000m .
Use environment
Our Company
Certifications
Our Agent
Packing & Delivery
Why Choose Us
What is your MOQ? MOV?
We don’t have MOQ for the standard items. And the MOV for the terms of FOB is 5000USD.
What are your terms of payment?
We accept T/T, L/C payment.
Can I pay by PAYPAL?
Yes, our Paypal account is “sales@xindali.com”
How long is the delivery date?
The standard lead time 2 weeks.
What certifications does this product have?
We have CE, Rohs, UL and TUV approvals.
Are you a manufacturer? Where is the factory?
Yes, we are manufacturer, our factory located in Wenzhou.
Can you do OEM?
Yes, we can offer customized service under OEM.
Why your price is higher than others?
If we are talking about the same qualitiy level, our price will be competitve.
How long is the guarantee of your products?
We have 5 years guarantee.
Do you have water-proof items?
Yes, our XDL22 and XDL722 series are IP65.
Can you provide me with samples for free?
Yes, the samples can be offered as free of charge.
Can you provide certificate of origin?
Yes, we can.
Can you customize the product for me?
Yes, we have our own R&D team and tool centre to make customized products.
Does Xindali have agent?
Yes, we have agent of Xindali brand in Italy, Sweden, Norway, Finland, Russia, Greece, Spain and UK.
What support can I get if I become your agent?
If you will be our agent, you will get the following VIP service,
* Professinal Technical support from Xindali Team
* Special Price support
* Lead Time support
* Samples boards support
* Payment support
We don’t have MOQ for the standard items. And the MOV for the terms of FOB is 5000USD.
What are your terms of payment?
We accept T/T, L/C payment.
Can I pay by PAYPAL?
Yes, our Paypal account is “sales@xindali.com”
How long is the delivery date?
The standard lead time 2 weeks.
What certifications does this product have?
We have CE, Rohs, UL and TUV approvals.
Are you a manufacturer? Where is the factory?
Yes, we are manufacturer, our factory located in Wenzhou.
Can you do OEM?
Yes, we can offer customized service under OEM.
Why your price is higher than others?
If we are talking about the same qualitiy level, our price will be competitve.
How long is the guarantee of your products?
We have 5 years guarantee.
Do you have water-proof items?
Yes, our XDL22 and XDL722 series are IP65.
Can you provide me with samples for free?
Yes, the samples can be offered as free of charge.
Can you provide certificate of origin?
Yes, we can.
Can you customize the product for me?
Yes, we have our own R&D team and tool centre to make customized products.
Does Xindali have agent?
Yes, we have agent of Xindali brand in Italy, Sweden, Norway, Finland, Russia, Greece, Spain and UK.
What support can I get if I become your agent?
If you will be our agent, you will get the following VIP service,
* Professinal Technical support from Xindali Team
* Special Price support
* Lead Time support
* Samples boards support
* Payment support
