Quick Details
-
Model Number:
-
TZ-6102
-
Protection Level:
-
IP65
-
Operating Temperature:
-
-5℃-+80℃
-
Max. Current:
-
10A
-
Type:
-
TZ-6 series
-
Material:
-
Aluminum alloy
-
contact form:
-
NO, NC
-
Operating frequency:
-
Mechanical:240 times/min; Electrical: 20times/min
-
Feature:
-
waterproof, oil-proof
-
Humidity:
-
<95% RH
-
Certification:
-
CCC, CE
Quick Details
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
XINGBO
-
Model Number:
-
TZ-6102
-
Protection Level:
-
IP65
-
Operating Temperature:
-
-5℃-+80℃
-
Max. Current:
-
10A
-
Type:
-
TZ-6 series
-
Material:
-
Aluminum alloy
-
contact form:
-
NO, NC
-
Operating frequency:
-
Mechanical:240 times/min; Electrical: 20times/min
-
Feature:
-
waterproof, oil-proof
-
Humidity:
-
<95% RH
-
Certification:
-
CCC, CE
Features:
Built-in TM series micro switch, strong aluminum cast shell, design for water-proof and oil-proof
Rated value and characteristics are as same as TM micro switch
Various of actuators that are taken convenience for using
Each switch is equipped with cable fixator
Standard size configuration M20x1.5 for conduit connector
Operating characteristics
|
Model |
TZ6001 |
TZ6002 |
TZ6003 |
TZ6004 |
TZ6043 |
TZ6101 |
TZ6102 |
TZ6103 |
TZ6104 |
TZ6143 |
|
OF(Max.) |
250-350g |
250-350g |
570g |
570g |
800g |
500g |
640g |
640g |
||
|
RF(Min.) |
114g |
114g |
170g |
170g |
240g |
100g |
230g |
230g |
||
|
PT(Max.) |
0.4mm |
0.5mm |
4mm |
4mm |
2mm |
1mm |
5mm |
5mm |
||
|
OT(Min.) |
5.5mm |
3.6mm |
6mm |
6mm |
5mm |
3.5mm |
6mm |
6mm |
||
|
MD(Max.) |
0.05mm |
0.05mm |
0.4mm |
0.4mm |
0.1mm |
0.12mm |
0.4mm |
0.4mm |
||
|
OP |
38.2± 0.8mm |
49.7± 1mm |
|
|
45.8± 0.8mm |
49.7± 0.8mm |
|
|||
