Quick Details
Quick Details
-
Place of Origin:
-
Japan
-
Engine Brand:
-
YTO
-
Weight:
-
3500 KG
Product Description
Specification
|
item
|
value
|
|
Rated Power (HP)
|
75HP
|
|
Type
|
Wheel Tractor
|
|
Condition
|
Used
|
|
By wheel
|
4WD/2WD
|
|
Usage
|
Farm Tractor
|
|
Drive Type
|
Gear Drive
|
|
Certificate
|
ISO
|
|
Place of Origin
|
Japan
|
|
Warranty
|
1 Year
|
|
Key Selling Points
|
Famous brand
|
|
Marketing Type
|
New Product 2020
|
|
Machinery Test Report
|
Provided
|
|
Video outgoing-inspection
|
Provided
|
|
Warranty of core components
|
1 Year
|
|
Core Components
|
Engine, Gear
|
|
Engine Brand
|
YTO
|
|
Applicable Industries
|
Farms, Home Use
|
|
Showroom Location
|
Pakistan, Argentina, Sri Lanka, South Africa, Kazakhstan
|
|
Weight
|
3500KG
|
|
|
|
|
Main Technical Parameters
(SH504)
|
|
|
|
|||
|
Horse Power(HP)
|
50
|
Engine Model
|
4100B-4a
|
|||
|
Rated Power (KW)
|
37
|
Rated Speed(rpm)
|
2000
|
|||
|
Gears
|
8+2
|
Min. Ground Clearance(mm)
|
334
|
|||
|
PTO (r/min)
|
766
|
Overall Dimensions(mm)
|
3325 x 1848 x 2350
|
|||
|
Tyre Size(mm)
|
8.3-20/11-32
|
Quality(kg)
|
2370
|
|||
|
Torque Reserve (%)
|
≥18%
|
Fuel consumption (g/kw h)
|
≤242
|
|||
|
Max. traction (KN)
|
17.6
|
Max. Lifting force (KN)
|
8
|
|||
Main Technical Parameters (SNH):
|
Model
|
SNH554
|
SNH704
|
SNH754
|
SNH804
|
|
Horse Power(HP)
|
55
|
70
|
75
|
80
|
|
Rated Power (KW)
|
40
|
51.5
|
55.1
|
58.8
|
|
Engine Model
|
4100B-2
|
SNH4102
|
SNH4102Z
|
SNH4102Z
|
|
Rated Speed(rpm)
|
2000
|
2400
|
2400
|
2400
|
|
Gears
|
10+2 / 8+2
|
10+2 / 8+2
|
10+2 / 8+2
|
10+2 / 8+2
|
|
Min. Ground Clearance(mm)
|
334
|
359
|
359
|
359
|
|
PTO (r/min)
|
766
|
783
|
783
|
783
|
|
Overall Dimensions(mm)
|
3350 x 1848 x 2357
|
3942 x 1930 x 2394
|
4043 x 1990 x 2540
|
4043 x 1990 x 2540
|
|
Tyre Size(mm)
|
8.3-20/11-32
|
8.3-24/14.9-30
|
8.3-24/14.9-30
|
8.3-24/14.9-30
|
|
Quality(kg)
|
2370
|
2500
|
2520
|
2520
|
|
Model
|
SNH904
|
SNH1004
|
SNH1104
|
SNH1204
|
|
Horse Power(HP)
|
90
|
100
|
110
|
120
|
|
Rated Power (KW)
|
67
|
73.5
|
80.9
|
91
|
|
Engine Model
|
WP4T90E20
|
WP4T100E20
|
WP6T110E20
|
WP6T120E20
|
|
Rated Speed(rpm)
|
2300
|
2300
|
2300
|
2300
|
|
Gears
|
12+12
|
12+12
|
12+12
|
12+12
|
|
Min. Ground Clearance(mm)
|
416
|
416
|
500
|
407
|
|
PTO (r/min)
|
540/750
|
540/750
|
540/1000
|
540/1000
|
|
Overall Dimensions(mm)
|
4516 x 2110 x 2765
|
4516 x 2110 x 2765
|
4115 x 1910 x 2657
|
4830 x 2300 x 3100
|
|
Tyre Size(mm)
|
12.4-24/16.9-34
|
12.4-24/16.9-34
|
13.6-28/16.9-38
|
14.9-28/18.4-38
|
|
Quality(kg)
|
3890
|
3890
|
4720
|
4850
|
Used Massey Tractor:
|
Model
|
1004
|
1104
|
1204
|
|
Horse Power(HP)
|
100
|
110
|
120
|
|
Engine Model
|
Perkins
|
Perkins
|
|
|
Rated Power (KW)
|
73.5
|
80.8
|
88.2
|
|
Rated Speed(rpm)
|
2200
|
2200
|
2200
|
|
Gears
|
12+4
|
12+4
|
12+4
|
|
Min. Ground Clearance(mm)
|
380
|
380
|
380
|
|
Wheelbase(mm)
|
2370
|
2486
|
2486
|
|
Overall Dimensions(mm)
|
4330 x 2235 x 2965
|
4330 x 2235 x 2965
|
4330 x 2235 x 2965
|
|
Tyre Size(mm)
|
14.9-24/18.4-34
|
14.9-24/18.4-34, 12.4-28/18.4-34, 14.9-24/18.4-34
|
14.9-24/18.4-34
|
|
Quality(kg)
|
3950
|
4050
|
4150
|
Used Kubo ta Tractor
|
Model
|
M704K
|
M854K
|
M954K
|
M1004Q
|
|
Horse Power(HP)
|
70
|
85
|
95
|
100
|
|
Engine Model
|
V3800-DI-T-ET19
|
V3800-DI-T-ES16
|
V3800-DI-T
|
V3800-DI-TI-ES02
|
|
Rated Power (KW)
|
51.5
|
62.5
|
69.9
|
73.5
|
|
Rated Speed(rpm)
|
2500
|
2500
|
2600
|
2600
|
|
Gears
|
8+8
|
12+12
|
12+12
|
12+12
|
|
Min. Ground
Clearance(mm) |
490
|
485
|
460
|
490
|
|
PTO(rpm)
|
540/720
|
540/720
|
540/720
|
540/720
|
|
Overall Dimensions(mm)
|
4110 x 1950 x 2530
|
4445 x 2215 x 2605
|
4210 x 2120 x 2650
|
4200 x 2130 x 2670
|
|
Tyre Size(mm)
|
14.9-26, 12.4-28/18.4-38,
16.9-34, 18.4-
34, 18.4-38 |
12.4-24/18.4-30
|
12.4-24/16.9-34
|
12.4-24/16.9-34
|
|
Quality(kg)
|
2400
|
3060
|
2995/2755
|
3135
|
|
|
|
|
|
|
Used Y T O Tractor
|
Model
|
MF454
|
MF554
|
MF704
|
LX804
|
|
Horse Power(HP)
|
45
|
55
|
70
|
80
|
|
Engine Model
|
Yangdong 4100
|
Yangdong 495
|
Dongchai 4108
|
LR4M5R22/0588、
LR4M5U22/0588E |
|
Rated Power (KW)
|
33.08
|
40.44
|
51.5
|
58.8
|
|
Rated Speed(rpm)
|
2200
|
2200
|
2200
|
2200
|
|
Gears
|
8+4
|
8+8
|
12+12
|
12+12
|
|
Min. Ground
Clearance(mm) |
350
|
350
|
400
|
430
|
|
PTO(rpm)
|
540/720,540/1000
|
540/720,540/1000
|
540/720,540/1000
|
540/720,540/1000
|
|
Overall Dimensions(mm)
|
3740 x 1645 x2420
|
3780 x 1685 x2134
|
3910 x 1780 x 2565
|
4350 x 2170 x 2740
|
|
Tyre Size(mm)
|
8.3-20/12.4-28
|
8.3-20/12.4-28
|
8.3-24,9.5-20,9.5-24/11-32, 14.9-30
|
11.2-28, 12.4-26(paddy
wheel)/13.6-38, 16.9-34(paddy wheel) |
|
Model
|
ME504
|
MG704
|
LY1204D
|
LX1304
|
|
Horse Power(HP)
|
50
|
70
|
120
|
130
|
|
Engine Model
|
Xinchai:A498BT
|
YTO YTR4108
|
LR4M3LR22/0882E
|
LR6A3LU22/0920E
|
|
Rated Power (KW)
|
36.8
|
51.5
|
88.4
|
95.6
|
|
Rated Speed(rpm)
|
2200
|
2200
|
2200
|
2200
|
|
Gears
|
8+4
|
10+2
|
12+12
|
12+4
|
|
Min. Ground
Clearance(mm) |
280
|
390
|
420
|
470
|
|
Mini turning
circle radius (m) |
3.4
|
4.5
|
5
|
6.5
|
|
Overall Dimensions(mm)
|
3675 x 1515 x 2735
|
4150 x 2040 x 2790
|
4350 x 2150 x 3030
|
5010 x 2360 x 3030
|
|
Tyre Size(mm)
|
8.3-20,8.3-20(paddy
wheel)/12.4-28, 11-28(paddy wheel) |
9.5-24/14.9-30(paddy wheel11-32)
|
13.6-24, 12.4-26(paddy wheel)/16.9-34, 13.6-38
|
14.9-26, 12.4-26(paddy
wheel)/18.4-38, 18.4-34 |
Packing & Delivery
10 sets in a 40HQ
Triangle wood and 10mm wire fixed.
