Quick Details
-
Fork Width:
-
550 or 685mm
-
Overall Dimensions:
-
1755 x 800 x 2068 mm (L x W x H)
-
Weight (KG):
-
71400 kg
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
China
-
Fork Length:
-
1150mm
-
Fork Width:
-
550 or 685mm
-
Overall Dimensions:
-
1755 x 800 x 2068 mm (L x W x H)
-
Weight (KG):
-
71400 kg
Product Description
Specification
|
Manufacture
|
|
RUNTX
|
Transmission Manufactuer
|
ZF/DANA
|
|||
|
Model designation
|
|
DM450/5
|
Transmission type
|
Auto-shift/Interlock
|
|||
|
Power units:battery,LP gas,mains power
|
|
Diesel
|
Clutch Type
|
Torque converter
|
|||
|
Operation:manual,pedestrian,stand-on,seated,order picker
|
|
Rider seated
|
Gear number
|
5F3R/4F4R
|
|||
|
Load capapcity(L1,L2,L3)
|
Q(kg)
|
45000/31000/16000
|
Tyres
|
|
|||
|
Load centre,First row(L1)
|
C(mm)
|
1800@6floor,2000@1-5
|
Drive wheels
|
18.00-25 40PR
|
|||
|
Load centre,Second row(L2)
|
C(mm)
|
3860
|
Steering wheels
|
18.00-25 40PR
|
|||
|
Load centre,Third row(L3)
|
C(mm)
|
6400
|
Type
|
Pneumatic
|
|||
|
Axle centre to spreader centre(L1-1/2 high)
|
X(mm)
|
2800
|
Pressure
|
10bar
|
|||
|
Wheelbase
|
y(mm)
|
6400
|
Quantity,Front/Rear
|
4月2日
|
|||
|
Dimension
|
|
|
Tanks Capacity
|
|
|||
|
Boom lift angle,raised/lowered
|
a/b(/。）
|
61/0
|
Hydraulic oil tank
|
800 liter
|
|||
|
Height boom lowered
|
h1(mm)
|
4945
|
Fuel tank
|
500 liter
|
|||
|
Lift height(L1,L2,L3)
|
h3(mm)
|
15900/14100/11350
|
Drive Axle
|
|
|||
|
Height,boom extended
|
h4(mm)
|
19000
|
Driver axle manufacturer
|
Kessler/Germany
|
|||
|
Height of cabin
|
h6(mm)
|
39000
|
Type
|
D102PL341
|
|||
|
Height,operators seat
|
h7(mm)
|
2840
|
|
|
|||
|
Towing coupling height
|
h10(mm)
|
600
|
|
|
|||
|
Twistlock height lowered
|
h13(mm)
|
1495
|
Steer Axle
|
|
|||
|
Overall length with spreader
|
l1(mm)
|
11618
|
Steering axle manufacturer
|
Kessler/Germany
|
|||
|
Overall length
|
l2(mm)
|
8410
|
Type
|
L102
|
|||
|
Overall width
|
b1/b2(mm)
|
4180/3400
|
Steering
|
Double action cylinder
|
|||
|
Width of soreader 20'/40'
|
b3(mm)
|
6050/12150
|
Brake System
|
|
|||
|
Ground clearance minimum
|
m1(mm)
|
345
|
Service brake:Hydraulic wet-disc
|
|
|||
|
Ground clearance,centre of wheelbase
|
m2(mm)
|
350
|
Parking brake:Electric released disc brake,enabled when power off
|
|
|||
|
Stacking aisle 20'container
|
Ast(mm)
|
10225
|
Hydraulic System
|
|
|||
|
Stacking aisle 40'container
|
Ast(mm)
|
13050
|
Twin piston pump
|
|
|||
|
Turning radius
|
Wa(mm)
|
8605
|
Maxiumum pressure:310 bar
|
|
|||
|
Minimum pivoting point distance
|
b13(mm)
|
3400
|
Load sensing system
|
|
|||
|
Wheelspan,Front wheels
|
b10(mm)
|
3030
|
Hydraulic cooler with electric motor
|
|
|||
|
Wheelspan,Rear wheels
|
b11(mm)
|
2786
|
Separate brake oil tank
|
|
|||
|
Weight
|
|
|
Boom
|
|
|||
|
|
unladen
|
laden
|
2xDual action lift cylinders
|
|
|||
|
weight km/h
|
71400
|
116400
|
1xDual action extension cylinder
|
|
|||
|
Load on drive axle kg
|
36400
|
101900
|
Spreader
|
|
|||
|
Load on steering axle kg
|
35000
|
14500
|
Handling ISO 20'-40' containers
|
|
|||
|
Performances
|
|
|
2xdamping cylinder
|
2xgearbox&brake system
|
|||
|
|
unladen
|
laden
|
Type
|
RTXZSP45
|
|||
|
Travelling speed km/h
|
25
|
21
|
Rotatd degrees deg
|
-105。/+195。
|
|||
|
Climbing ability %
|
30
|
28.5
|
Sidershift mm
|
-1
|
|||
|
Tractive force kn
|
325
|
_____
|
Truck Safeties
|
|
|||
|
Lifting speed m/s
|
0.39
|
0.28
|
Error display system
|
|
|||
|
Lowering speed m/s
|
0.39
|
0.39
|
Counting system for containers
|
|
|||
|
Cabin
|
|
|
Weighting system(low precision)
|
|
|||
|
Movable closed cabin
|
|
|
Electric anti-overload system
|
|
|||
|
Equiped with air-conditioner.cooling/heating function
|
|
|
Full Can-bus control system
|
|
|||
|
Noise level at driver's ear dBA
|
74
|
|
Direction aearshift interlock
|
|
|||
|
Engine
|
|
|
Parking brake enabled when power off
|
|
|||
|
Brand
|
Cummins
|
VOLVO
|
Seat switch
|
|
|||
|
Type
|
QSM 11
|
TAD1151
|
|
|
|||
|
Cylinder number/Displacement
|
6/10820cm3
|
6/10820cm3
|
Spreader Safeties
|
|
|||
|
Rated power@rated speed
|
250kw@2100rpm
|
265kw@2100rpm
|
Locking/unlocking only after landing
|
|
|||
|
Maximum torque
|
1674NM@1500rpm
|
1780NM@1260rpm
|
Lofting/Lowering only when the 4 twistlocks on same position
|
|
|||
|
Rated current of alternator
|
150A
|
150A
|
Acticollsion rotation limit switch
|
|
|||
|
Battery
|
24V(2X12/150)
|
24V(2X12/150)
|
|
|
|||
