- Product Details
- {{item.text}}
Quick Details
-
PWR:
-
unit power indicator
-
STA:
-
Audio signal indicator
-
Audio input impedance:
-
10K
-
Audio output impedance:
-
600Ω
-
Interface mode:
-
Unbalanced interface
-
Input output range ratio:
-
1/1
-
Frequency response:
-
20HZ-20KHZ
-
Audio sampling rate:
-
24bit/96KHZ
-
Signal to noise ratio(SNR):
-
≥75dB
-
Audio interface:
-
RCA connector
Quick Details
-
Brand Name:
-
promaxion
-
Model Number:
-
M-AF04(SC)
-
Place of Origin:
-
Guangdong, China
-
PWR:
-
unit power indicator
-
STA:
-
Audio signal indicator
-
Audio input impedance:
-
10K
-
Audio output impedance:
-
600Ω
-
Interface mode:
-
Unbalanced interface
-
Input output range ratio:
-
1/1
-
Frequency response:
-
20HZ-20KHZ
-
Audio sampling rate:
-
24bit/96KHZ
-
Signal to noise ratio(SNR):
-
≥75dB
-
Audio interface:
-
RCA connector
Products Description
|
Parameter
|
|
Description
|
|
|
Audio
|
Audio input impedance
|
10K
|
|
|
|
Audio output impedance
|
600Ω
|
|
|
|
Interface mode
|
Unbalanced interface
|
|
|
|
Input output range ratio
|
1/1
|
|
|
|
Frequency response
|
20HZ-20KHZ
|
|
|
|
Audio sampling rate
|
24bit/96KHZ
|
|
|
|
Signal to noise ratio(SNR)
|
≥75dB
|
|
|
|
Audio interface
|
RCA connector
|
|
|
Optical
|
Transmission wavelength
|
TX：1310nm、RX:1550nm
|
|
|
|
Optical interface
|
FC/SC（Default SC）
|
|
|
|
Transmitted optical power
|
Max 10dB/20KM
|
|
|
|
Receiving sensitivity
|
-35@155MB/S
|
|
|
|
Optical dynamic range
|
-39dB~-42dB
|
|
|
|
Optical maximum allowable chain loss
|
25dB
|
|
|
|
transmission distance
|
20KM(single mode)
|
|
|
Technical indicators
|
Power
|
DC 5V/1A
|
|
|
|
Power dissipation
|
4.8W@DC5V
|
|
|
|
Temperature
|
Operation temperature: -20 ℃-+80℃
|
|
|
|
Humidity
|
Operation Humidity: 0 - 95% （non-condensing ）
|
|
|
|
Mean Time Between Failures（MTBF）
|
＞one hundred thousand hours
|
|
