Quick Details
-
Warranty:
-
30 years
-
Brand Name:
-
Bluesun Solar
-
Model Number:
-
BSM600M10-72HNH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278*1134*30mm
-
Color:
-
Black
-
Cell Type:
-
Monocrystalline
-
Weight:
-
32.7kg
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP68
-
Safety Class:
-
II
-
Maximun System Voltage:
-
1500V/DC(IEC)
-
Maximun Series Fuse:
-
30A
-
Operating Temperature:
-
-40°C~ +85°C
-
Certificate:
-
CE; TUV; VDE
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Bifacial, Double-glass, N-TYPE, TOPCON
-
Panel Efficiency:
-
23.2%
-
Warranty:
-
30 years
-
Brand Name:
-
Bluesun Solar
-
Model Number:
-
BSM600M10-72HNH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278*1134*30mm
-
Color:
-
Black
-
Cell Type:
-
Monocrystalline
-
Weight:
-
32.7kg
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP68
-
Safety Class:
-
II
-
Maximun System Voltage:
-
1500V/DC(IEC)
-
Maximun Series Fuse:
-
30A
-
Operating Temperature:
-
-40°C~ +85°C
-
Certificate:
-
CE; TUV; VDE
Product Description
|
SPECIFICATIONS
|
|
|
|
|
|
|||||
|
Module Type
|
BSM580M10-72HNH
|
BSM585M10-72HNH
|
BSM590M10-72HNH
|
BSM595M10-72HNH
|
BSM600M10-72HNH
|
|||||
|
Maximum Power (Pmax/W)
|
580
|
585
|
590
|
595
|
600
|
|||||
|
Operating Voltage (VmpM
|
43.28
|
43.48
|
43.68
|
43.88
|
44.08
|
|||||
|
Operating Current (lmp/A)
|
13.41
|
13.47
|
13.53
|
13.59
|
13.65
|
|||||
|
Open-Circuit Voltage (Voc/ V)
|
51.64
|
51.84
|
52.04
|
52.24
|
52.44
|
|||||
|
Short-Circuit Current (lsc/A)
|
14.29
|
14.33
|
14.37
|
14.41
|
14.45
|
|||||
|
Module Efficiency(%)
|
22.5
|
22.7
|
22.8
|
23
|
23.2
|
|||||
|
STC: Iradiance 1000W/m²,Cell Temperature 25°C, Air Mass AM1.5
|
|
|
|
|
|
|||||
|
|
|
|
|
|
||||||
Certificates
Production Process
Packing&Delivery
Packing Configuration : 36pcs/carton, 720pcs/40hq
