Quick Details
-
Function:
-
GPS, HANDSFREE, Amplifier, DSP, CarPlay, Mirror Link, android auto, picture in picture, Built-in Microphone, File Manager, Car Steering Wheel Control
-
Warranty:
-
12 Months
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
PENHUI
-
10.1 inch Screen Resolution:
-
1280*720 QLED Screen
-
9.19 inch with Knobs:
-
1280*640 IPS Screen
-
2K 10.36 inch screen:
-
2000*1200 Screen
-
RAM/RAM:
-
6GB & 128GB
-
CarPlay/ Android Auto:
-
Wireless
-
Internet:
-
Wi-Fi/4G
-
DSP:
-
Built in
-
Amplifier IC:
-
TDA-7850
-
GPS/GLONASS:
-
Supported
-
Handsfree Module:
-
BC5.1 Support Aptx formate
Quick Details
-
Car Fitment:
-
BYD
-
Screen Size:
-
10.1"
-
Resolution:
-
1280*720
-
Function:
-
GPS, HANDSFREE, Amplifier, DSP, CarPlay, Mirror Link, android auto, picture in picture, Built-in Microphone, File Manager, Car Steering Wheel Control
-
Warranty:
-
12 Months
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
PENHUI
-
10.1 inch Screen Resolution:
-
1280*720 QLED Screen
-
9.19 inch with Knobs:
-
1280*640 IPS Screen
-
2K 10.36 inch screen:
-
2000*1200 Screen
-
RAM/RAM:
-
6GB & 128GB
-
CarPlay/ Android Auto:
-
Wireless
-
Internet:
-
Wi-Fi/4G
-
DSP:
-
Built in
-
Amplifier IC:
-
TDA-7850
-
GPS/GLONASS:
-
Supported
-
Handsfree Module:
-
BC5.1 Support Aptx formate
General specifications:
Operating system: Android 10
Processor: 1.8 GHz-8 cores (Unisoc UIS7862)
RAM: 6 GB (LPDDR4) or 8 GB
Built-in memory: 128 GB or 256 GB
GPS + GLONASS navigation module and antenna
3 USB ports for flash drives up to 256 GB. Support HDD, but not more than 1 TB (NTFS format)
4G modem with external SIM holder
Wireless CarPlay (support Android Auto/CarPlay)
Super Sleep mode up to 3 days (fast turn on 1.5 seconds). Sleep consumption only 0.01 Ma
Advantage for 750 Pro
Built in Digital Amplifier Infineon Ma-12070P X 4 pcs
- Compare with TDA-7850 , the amplifier is upgraded from 45Wx 4CH to 160W x 4CH
- Digital amplifier will lower the hot
- Working Voltage is upgraded from 12V to 25V
- Support the optical output with I2S signal , donot need pass the internal DSP
- Horizontal metal body , easy for cooling
- Support coaxial output ( then original amplifier with coaxial signal do not need be transferd by can bus ) , it can be output from DVD to original amplifier directly
Professinal DSP processor
- Support the independently adjusting the every channel
You Also receive Russian software with improvements of update + technical support and warranty from Russian programmers and engineers . (subscribe to our youtube channel for video lessons and news)
The best bluetooth qualcomm module with aptx HD support is installed. This module uses the latest noise suppression and microphone control systems, which allows you to set up speaker for your car.
The productive processor along with the memory lddr4 6GB & 8GB gives excellent results in speed and leaves a power reserve for the next few years.
Voice control radio (do not activate!). For example, "call mom" or "start navigator"
New topics added. There are several options available for every taste. (change is done by pressing the RP
button for a long time)
Display:
| 9.19 inch Screen with knobs | 1280*640 IPS Screen 800 LS |
| 10.1 inch screen | 1280*720 QLED Screen |
| 10.36 inch Screen | 2000*1200 2k Screen |
Audio:
RCA outputs 4 + 1 (sub) 2 volts
Amplifier TDA 7850 (MOSFET, Hi-Fi)To 4*45 W. (Do not confuse with the budget TDA 7851l)
Support for acoustics 2 ohms and 4 ohms
Sound Processor DSP Rohm 32107 9 (not hi-fi) on the delay Channel No
48 band equalizer in general on all channels
RF and LF cut off filters usually front and rear
AUX (1 video input and 2 line audio input)
Radio:
Radio module : HD Radio NXP 6686 (Easy reception even with a weak signal);
FM 87.5-108Mhz 36 cells to record favorite stations in memory;
AM 522-1161Khz 18 cells to record favorite stations in memory;
The ability to edit station names (preliminarily you need to run AS (automatic search);
RDS: Support the type the frequency manually.
Video:
1 video input for rear view camera: 720p; support AHD cameras;
1 video input for camera Front view: 720p, in settings, you can set the front camera to turn on automatically after turning off the rear camera for 5, 10,15 seconds
AUX video input for external video source including
DVR with AV Output ;
you can use a DVD USB drive compatible with Android ;
Connecting digital TV tuner ;
On 4 TV antennas DVB-T2 with touch control ;
Video ouput is via USB adapter;
Internet :
1) All kinds of configuration has the functions Wi-Fi/Hotspot access of Mobile :
2) the configuration have the function of 4G
Built-in 4G modem with a SIM-holder; Built -out GSM antennas bundled (2 pieces) To be installed at the best signal reception location
Bluetooth:
Two Bluetooth modules: Qualcomm 5.1 version with aptX + Intel data codec (OBD, TPMS and so on)
The new aptX codec allows your smartphone or other device to transmit sound as close to CD
Separate volume adjustment in talk mode
Bluetooth data for data transmission. Up to 8 connections simultaneously. (OBD + TPMS + phone can work with the device at the same time)
Bluetooth OBD and TPMS. Car radio can work with two or more data channels simultaneously via Bluetooth. (You need to buy appropriate devices and software for Android OS)
Display MP3 tags on car radio screen (A2DP)
Remote Bluetooth antenna for better reception
Built-in microphone is used for voice control in Android system
Remote microphone is used for handsfree
Call list, contacts, selected contacts, quick dial
Microphone volume control
Custom microphone amplifier
