Quick Details
-
Use:
-
Warehouse Rack
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Everunion
-
Model Number:
-
CRS
-
Depth:
-
1.8-2.5mm
-
Weight Capacity:
-
4 tons
-
Width:
-
800-1200mm
-
Height:
-
3000mm
-
Certification:
-
ce
-
color:
-
as customer 's need
-
certificate:
-
CE/ISO certificate
-
material:
-
Q235B steel
-
height:
-
2000-13000mm
-
port:
-
shanghai port
-
Usage:
-
Storage
-
Product name:
-
Heavy Duty Pallet Rack
-
Application:
-
Goods Storage
-
Size:
-
Customized Accepted
Quick Details
-
Type:
-
Cantilevered
-
Material:
-
Q235b steel
-
Feature:
-
Corrosion Protection
-
Use:
-
Warehouse Rack
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Everunion
-
Model Number:
-
CRS
-
Depth:
-
1.8-2.5mm
-
Weight Capacity:
-
4 tons
-
Width:
-
800-1200mm
-
Height:
-
3000mm
-
Certification:
-
ce
-
color:
-
as customer 's need
-
certificate:
-
CE/ISO certificate
-
material:
-
Q235B steel
-
height:
-
2000-13000mm
-
port:
-
shanghai port
-
Usage:
-
Storage
-
Product name:
-
Heavy Duty Pallet Rack
-
Application:
-
Goods Storage
-
Size:
-
Customized Accepted
Industrial Warehouse Arm Cantilever Rack Heavy Duty Cantilever Racks
1) The cantilever racking is suitable for storing long, circular or irregular shape articles
2) It's suitable for the storage and reorganization of the tall and slender good
3) There are two structures_single arm and double arms.
5) It fit for small space and low warehouse
6) It is easy to fetch or place goods.
Arm cantilever rack feature
**Apply to long or scroll-shaped long items storage
**Low space utilization rate about 35-50%
**Suitable for building materialproduction plant, furniture manufcturer or supermarket
**Can be equipped with panel according to requirements
Light cantilever racking specs:200*80*2.0-3.0
| upright height | cantilever length | single face load bearing | double face load bearing |
| 2000-3000 | 400 | 3250 | 6500 |
| 500 | 2700 | 5400 | |
| 600 | 2300 | 4600 | |
| 700 | 2000 | 4010 | |
| 800 | 1800 | 3550 |
Middle cantilever racking specs:250*90*2.0-3.0
| upright height | cantilever length | single face load bearing | double face load bearing |
| 2000-3000 | 400 | 3250 | 6500 |
| 500 | 2700 | 5400 | |
| 600 | 2300 | 4600 | |
| 700 | 2000 | 4010 | |
| 800 | 1800 | 3550 |
Heavy cantilever racking specs:300*90*2.0-3.0
| upright height | cantilever length | single face load bearing | double face load bearing |
| 2000-6000 | 400 | 8350 | 16700 |
| 500 | 7350 | 14700 | |
| 600 | 6600 | 13150 | |
| 700 | 5950 | 11900 | |
| 800 | 5450 | 10850 |
Features about Cantilever racks:
1) Different sizes can be made, the racks are made by rolling machines
2) Loading capacity: 1,000kg/Arm
3) Finish: Powder coated/Paint
4) Easily assembled, Layers can be adjusted as required
5) Packing: Polybag
6) The highest can be made till to 6000mm
7) Designed according to customers' size and loading capacity
8) Different colors for choice
9) If there is plan of warehouse for reference, please send to us
10)Lead Time: About 30 days after receipt of deposit.
11)Payment Terms: 30% deposit & 70& balance against delivery / copy of B/L or L/C at sight.
Cantilever rack stucture is rigid and durable ;the post and arms are of special steel section.It can be single side or double side.It is very good for storage of long items and irregular shape item,such as steel bar,pipeline and wood plank.It is suitable for low headroom warehouse to improve space utilization.The system can handle by standard forklift truck,but require wide aisle or handle with overhead crane.
What services do we provide?
- Free and professional warehouse rack CAD drawing design;
-
But pls kindly supply these info as follow:
- Size of your warehouse (Length x Width x Clear height)
- Size (W*D*H) &weight of pallet (after loading)
- How many levels you would like
- Alibaba Trade Assurance.
Pre-sales Service:
1). Our Excellent Service
You can send us your cad drawing we will give you a quick online quote, or you just tell us your tridimensional dimension of your warehouse we can design and draw drawings for you within 48 hours.
We promise to reply with a price within 24 hours - sometimes even within the hour.
If you need an advice,
pls call us or email us
, we will answer your questions immediately.
After-sales Service:
1).We will remind you before boat arrival
2)We will help cusotmer successly Customs clearance,we can supply the related certificate as customer's demand
3)If customer can't installed ,our engineer can go abroad to guide
Products will use our e xperienced export packing: (1) packed by wooden bars,crates,metals stripes,films for bulk goods,and cartons for accessories. (2)paper cartons for accessories.
Shanghai port , the closest port to us, is recommended strongly as loading port. Nanjing port is also available, but not recommended because of much higher cost of in-land trucking transportation from our factory.
