- Product Details
- {{item.text}}
Quick Details
-
Core Components:
-
Laser sorce
-
Place of Origin:
-
Henan, China
-
Weight (KG):
-
87 KG
-
Product name:
-
Laser Rust Removal Machine
-
Application:
-
Surface Paint Cleaning
-
Function:
-
Metal Rust Surface Laser Cleaning
-
Laser Power:
-
300W
-
Key word:
-
Portable Handheld Laser Cleaning Machine
-
Cleaning Process:
-
Non-contact Laser Cleaning
-
Laser source:
-
IPG Raycus Max JPT
-
Feature:
-
Accurate Cleaning
-
Cooling method:
-
Air Cooled
-
Clean way:
-
Non-touch 360 Laser Cleaning
Quick Details
-
Power:
-
300W
-
Laser Type:
-
Pulse Laser
-
Laser Source Brand:
-
JPT
-
Core Components:
-
Laser sorce
-
Place of Origin:
-
Henan, China
-
Weight (KG):
-
87 KG
-
Product name:
-
Laser Rust Removal Machine
-
Application:
-
Surface Paint Cleaning
-
Function:
-
Metal Rust Surface Laser Cleaning
-
Laser Power:
-
300W
-
Key word:
-
Portable Handheld Laser Cleaning Machine
-
Cleaning Process:
-
Non-contact Laser Cleaning
-
Laser source:
-
IPG Raycus Max JPT
-
Feature:
-
Accurate Cleaning
-
Cooling method:
-
Air Cooled
-
Clean way:
-
Non-touch 360 Laser Cleaning
What is the laser cleaning machine?
Removal of oils, resins, glues, dust, stains, and production residues.
Roughening of metal surfaces.
1:
Paint removal, rust removal, and oil stain removal before welding or bonding;
treatment of oxides and residues after welding.
2:
Mold cleaning, such as tire molds, electronic molds, and food molds.
Removal of oil stains after precision component production and processing.
3:
Treatment of oxides, paint removal, and rust removal during the production or
maintenance of aerospace weapons, ships.
4:
Cleaning of metal surfaces in narrow spaces.
Cleaning of cultural relics, rocks, and exterior surfaces of buildings.
5:
Cleaning of mechanical parts, cleaning of pipes and fittings, cleaning of
automobile parts, cleaning of old paint on aircraft, etc.
Features and Advantages:
* Stable Frame, Effortless Pushing and Pulling. High-strength structure, ergonomic design.
* Large size tubeless tire. Strong anti-seismic performance. Easy to cope with complex road conditions. Brake on both sides to lock safely. Effortless parking on slopes.
* Light cleaning head(only 620g), convenient for long time handheld operation. Double protection design, reduce galvanometer damage.
* Punched heat dissipation holes. Sloped waterproof design. Effectively protect the laser source and adapt to complex environments
* Air cooling for heat dissipation, lower energy consumption. Cleaning head chuck+elastic strap design. Double fixation protection, no fear of complex
* Stable Frame, Effortless Pushing and Pulling. High-strength structure, ergonomic design.
* Large size tubeless tire. Strong anti-seismic performance. Easy to cope with complex road conditions. Brake on both sides to lock safely. Effortless parking on slopes.
* Light cleaning head(only 620g), convenient for long time handheld operation. Double protection design, reduce galvanometer damage.
* Punched heat dissipation holes. Sloped waterproof design. Effectively protect the laser source and adapt to complex environments
* Air cooling for heat dissipation, lower energy consumption. Cleaning head chuck+elastic strap design. Double fixation protection, no fear of complex
road conditions.
* Passed multiple stringent tests (high temperature, vibration, fatigue, cable bending test, etc.) in the industry. Reliable quality, stable and durable.
* Passed multiple stringent tests (high temperature, vibration, fatigue, cable bending test, etc.) in the industry. Reliable quality, stable and durable.
Technical Parameters
|
Model
|
BLC-200
|
BLC-300
|
|
|
Laser Power
|
200W
|
300W
|
|
|
Laser Wavelength
|
1064nm
|
|
|
|
Operating Mode
|
Pulse
|
|
|
|
Fiber Length
|
5m
|
|
|
|
Pulse Width
|
10-500ns
|
|
|
|
Modulation Frequency
|
1-4000KHz
|
1-1000KHz
|
|
|
Adjustable Field
|
0-130mm
|
|
|
|
Input Voltage
|
AC220V±10%
|
|
|
|
Cooling Method
|
Air Cooling
|
|
|
|
Host Size
|
1170*660*1100mm
|
|
|
|
Net Weight
|
82kg
|
87kg
|
|
Sample Show
BYlaser laser cleaning machine can efficiently remove resin, oil stains, stains, dirt, rust, coating, plating, and paint on the surface of the workpiece, meeting the cleaning requirements of complex shapes and fine positioning in the industrial processing field, achieving a cleaner cleaning effect with higher cleanliness, and a higher overall cost.
Feedback
Why Choose Us
FAQ
1. Who are we?
We are based in luoyang city,Henan Province ,China,start from 2010,sell to Domestic Market(50.00%),North America(8.00%),Eastern Asia(8.00%),Western Europe(8.00%),Sourh America(4.00%),Southeast Asia(4.00%),Africa(4.00%),Oceania(4.00%),Northern Europe(4.00%),Southern urope(4.00%),South Asia(2.00%).There are total about 50-100 people in our office.
2.How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment.
We are based in luoyang city,Henan Province ,China,start from 2010,sell to Domestic Market(50.00%),North America(8.00%),Eastern Asia(8.00%),Western Europe(8.00%),Sourh America(4.00%),Southeast Asia(4.00%),Africa(4.00%),Oceania(4.00%),Northern Europe(4.00%),Southern urope(4.00%),South Asia(2.00%).There are total about 50-100 people in our office.
2.How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment.
3.What should I do when something goes wrong with the laser?
We offer a one-year warranty. In warranty, we will provide the broken items free of charge. Beyond the warranty period, we still provide maintenance service.
4.Are you a manufacturer or a trading company?
We are a manufacturer established in 2010 ,now in Luoyang CN. Committed to providing the majority of users with economic,high-quality laser equipment. Welcome to our factory.
5.How long does it take to learn the laser?
The machine is easy to learn with teaching video, also we can help you to learn the laser online. Usually it will take a few hours to operate the laser ,But it will take a bit of trial and error to learn what speed and power settings to use with different materials. So we include a comprehensive guide with your system that has recommended speed and power settings for various materials with which you will be working.
6.Will the laser machine be safe during transport?
(1) Inner: plastic stretch film and white foam.
(2)Middle: small pieces of wood and screws.
(3)outside: standard export wooden case.
So,the laser machine will send to you safely. In case the machine was damaged , please contact us ,We will process the replacement as soon as possible to ensure that it arrives in time.
We offer a one-year warranty. In warranty, we will provide the broken items free of charge. Beyond the warranty period, we still provide maintenance service.
4.Are you a manufacturer or a trading company?
We are a manufacturer established in 2010 ,now in Luoyang CN. Committed to providing the majority of users with economic,high-quality laser equipment. Welcome to our factory.
5.How long does it take to learn the laser?
The machine is easy to learn with teaching video, also we can help you to learn the laser online. Usually it will take a few hours to operate the laser ,But it will take a bit of trial and error to learn what speed and power settings to use with different materials. So we include a comprehensive guide with your system that has recommended speed and power settings for various materials with which you will be working.
6.Will the laser machine be safe during transport?
(1) Inner: plastic stretch film and white foam.
(2)Middle: small pieces of wood and screws.
(3)outside: standard export wooden case.
So,the laser machine will send to you safely. In case the machine was damaged , please contact us ,We will process the replacement as soon as possible to ensure that it arrives in time.
