Quick Details
-
Voltage:
-
380v/3ph/50hz
-
Dimension(L*W*H):
-
780*600*1020mm
-
Weight:
-
215KG
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Ruihong
-
Model Number:
-
RH-100HP
-
Voltage:
-
380v/3ph/50hz
-
Dimension(L*W*H):
-
780*600*1020mm
-
Weight:
-
215KG
Product Description
Product Details
| Modle | RH-10HP | RH-15HP | RH-20HP | RH-30HP | RH-50HP | RH-60HP |
| Motor power | 7.5kw | 11kw | 15kw | 22kw | 37kw | 45kw |
| Flow /pressure | 1.2/0.7 | 1.71/0.7 | 2.3/0.7 | 3.8/.07 | 6.5/0.7 | 8.5/0.7 |
| 1.1/0.8 | 1.65/0.8 | 2.25/0.8 | 3.6/0.8 | 6.2/0.8 | 8.0/0.8 | |
| 0.9/1.0 | 1.32/1.0 | 1.8/1.0 | 3.0/1.0 | 5.6/1.0 | 7.5/1.0 | |
| 0.8/1.2 | 1.1/1.2 | 1.5/1.2 | 2.6/1.2 | 5.0/1.2 | 7.0/1.2 | |
| Lubricating oil capacity(L) | 12 | 16 | 16 | 26 | 26 | 28 |
| Lenth mm | 780 | 1050 | 1050 | 1300 | 1460 | 1460 |
| Wide mm | 600 | 700 | 700 | 850 | 1000 | 1000 |
| Height mm | 12020 | 1100 | 1100 | 1160 | 1380 | 1380 |
| Weight(kg) | 215 | 335 | 335 | 465 | 630 | 825 |
| Modle | RH-75HP | RH-100HP | RH-125HP | RH-150HP | RH-175HP | RH-200HP |
| Motor power | 55 | 75 | 90 | 110 | 132 | 160 |
| Flow /pressure | 10.5/0.7 | 13.2/0.7 | 16.2/0.7 | 21/.07 | 24.60.7 | 31/0.7 |
| 10.0/0.8 | 13.0/0.8 | 15.8/0.8 | 20./0.8 | 2.30/0.8 | 30/0.8 | |
| 8.5/1.0 | 10.9/1.0 | 14.0/1.0 | 18.0/1.0 | 21.0/1.0 | 26/1.0 | |
| 7.6/1.2 | 9.8/1.2 | 12.8/1.2 | 16.0/1.2 | 18.5/1.2 | 22/1.2 | |
| Lubricating oil capacity(L) | 54 | 54 | 72 | 90 | 90 | 90 |
| Lenth mm | 1900 | 1900 | 1900 | 2300 | 2300 | 2500 |
| Wide mm | 1250 | 1250 | 1250 | 1470 | 1470 | 1470 |
| Height mm | 1605 | 1605 | 1605 | 1840 | 1840 | 1840 |
| Weight(kg) | 1130 | 1230 | 1325 | 1520 | 1710 | 2800 |
