Quick Details
-
Customized support:
-
Other
-
Brand Name:
-
OEM / Danhao
-
Model Number:
-
OL180D
-
Place of Origin:
-
Jiangsu, China
-
Horsepower:
-
Other
-
Power Source:
-
DC12V/24V/48V
-
Outlet Size:
-
G1/4
-
Power:
-
120W
-
Noise dB(A):
-
≤56
-
Motor Material:
-
Copper
-
Net Weight (Kg):
-
2.6KG
-
Input Power (W):
-
120W
-
Certification:
-
CE
Quick Details
-
Application:
-
Other
-
Pressure:
-
Other
-
Warranty:
-
Other
-
Customized support:
-
Other
-
Brand Name:
-
OEM / Danhao
-
Model Number:
-
OL180D
-
Place of Origin:
-
Jiangsu, China
-
Horsepower:
-
Other
-
Power Source:
-
DC12V/24V/48V
-
Outlet Size:
-
G1/4
-
Power:
-
120W
-
Noise dB(A):
-
≤56
-
Motor Material:
-
Copper
-
Net Weight (Kg):
-
2.6KG
-
Input Power (W):
-
120W
-
Certification:
-
CE
Product Parameters
| MODELNUMBERS | OL180D Single Stage | OL180D Double Stage | |
| Rated Voltage (V/Hz) | DC12V/24V/48V | DC12V/24V/48V | |
| Input Power (W) | 120W | 120W | |
| Vacuum Flow (Max.) | 55L | 28L | |
| Vacuum Degress | KPA | -90 | -98 |
| mmHg | -680 | -740 | |
| Noise dB(A) | ≤56 | ≤56 | |
| Speed | 1800 | 1800 | |
| Motor Material | Copper | Copper | |
| Insulation Class | B | B | |
| Thermal Protector | 135±5℃ | 135±5℃ | |
| Use ambient temperature (℃) | MIN.-20℃ ~ MAX. 40℃ | MIN.-20℃ ~ MAX. 40℃ | |
| Driver size | 130*70*30mm | 130*70*30mm | |
| Machine Size (mm) | 172*89*143 | 172*89*143 | |
| Installation Dimension (mm) | 114*70(M6) | 114*70(M6) | |
| Inlet & Exhaust Specifications | G1/4 | G1/4 | |
| Net Weight (Kg) | 2.6 | 2.6 | |
