Quick Details
-
Forend plate size:
-
158*16*3mm
-
Forend plate:
-
Round Head
-
Backset:
-
50mm
-
Suitable cylinder:
-
European standard cylinder
-
Standard:
-
EN 12209
-
Suitable for:
-
Fire Proof Door
-
MOQ:
-
500PCS
-
Door Thick:
-
35-60mm
-
Sample:
-
Freely
-
Certification:
-
CE / Intertek
Quick Details
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
OEM
-
Product Name:
-
Sliding door lock
-
Forend plate size:
-
158*16*3mm
-
Forend plate:
-
Round Head
-
Backset:
-
50mm
-
Suitable cylinder:
-
European standard cylinder
-
Standard:
-
EN 12209
-
Suitable for:
-
Fire Proof Door
-
MOQ:
-
500PCS
-
Door Thick:
-
35-60mm
-
Sample:
-
Freely
-
Certification:
-
CE / Intertek
Product Description
EN12209
CE
certificate
FIRE
rated Sash lock 6572Z
|
50SD
|
Paramenter
|
|
Backset
|
50mm
|
|
Fire test -
Steel fire door
|
260 mins
|
|
Fire test -
Timber fire door
|
111 mins
|
|
CE certificate
(Intertek)
|
3 X 9 1 0 G 3 B C 2 0
|
Product Information
|
Intended use
|
Yes/No
|
Comments
|
Reference
|
|
On hinged doors
|
Yes
|
Locks are tested for side force and end force
|
EN12209:2016
|
|
Supported lock application
|
Yes
|
Tested in accordance with 5.5.1 and 5.11.3 using the fixture 20 or 29 and/or 5.11.5 using fixture 32 with support
|
|
|
Suitability for use on smoke control / fire resistance doorset
|
Yes
|
See manufacturers declaration referring to a test according to EN 1634–1 or declaration of melting point of the relevant latching
parts and if applicable the duration of the proven smoke control and/or fire resistance
|
|
|
Lock for use with unsprung handle
|
Yes
|
The lock shall conform to 5.4.6, minimum follower restoring torque of 0,8 Nm
|
|
CE Certification
Declaration of Performance (DoP)
Related Products
Packing&Shipping
1PC/BOX, 20PCS/CTN, 1000PCS/PALLET
Product testing
Durability test (Hinge)
Durability test (Mortise lock)
Test Temperature
Durability test(Cylinder)
Durability test (Handle)
Corrosion resistance
Company Introduction
JIANHUA
Group has 900 workers which covers 133,000 square meters (33 acres), specialize in Architectural hardware for doors (Rim lock / Mortise lock / Lever handle / Profile cylinder / Hinge).
We have 3 items,
(1) Rim lock to West Africa which outputs $20 million,
(2) Rim lock to North Africa / South America / Middle East which outputs $15 million,
(3) Mortise lock & lever handle & Hinge & Profile cylinder for fire rated door which outputs $10 million.
We have passed Quality Management System: ISO9001:2015; Fire rated Products have got relevant CE certification \ Fire test and Performance certification.
Mortise lock have CE certification according to EN12209 and EN1634-1
Hinge have CE certification according to EN1935 and EN1634-1
Brass profile cylinder has been verified according to EN1303
Lever handle has been verified according to EN1906
We have our own workshops \ own funds and stable production & management team.
To realize Manufacture and Creation, we continue to improve equipment automation.
VALUES:
Concentration, Innovation, Passion, Perfection
