Quick Details
-
Warranty:
-
30 years
-
Brand Name:
-
Amso Solar
-
Model Number:
-
AS200S9-40
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1100*880*30mm
-
Junction Box:
-
IP67 Rated Waterproof
-
Frame:
-
Anodized Aluminium Alloy
-
Solar cell:
-
Mono 210*210 Cell
-
Connector:
-
Compatible Connector
-
Weight:
-
10 kg
-
Front Cover:
-
3.2mm High Transmission Low Iron
-
Keywords:
-
24v solar panel price philippines
-
Key word:
-
solar panel 200w
-
Certificate:
-
CE, TUV, IEC, IOS
Quick Details
-
Cell size:
-
210mmx210mm
-
Type:
-
PERC, standard
-
Panel Efficiency:
-
200w
-
Warranty:
-
30 years
-
Brand Name:
-
Amso Solar
-
Model Number:
-
AS200S9-40
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1100*880*30mm
-
Junction Box:
-
IP67 Rated Waterproof
-
Frame:
-
Anodized Aluminium Alloy
-
Solar cell:
-
Mono 210*210 Cell
-
Connector:
-
Compatible Connector
-
Weight:
-
10 kg
-
Front Cover:
-
3.2mm High Transmission Low Iron
-
Keywords:
-
24v solar panel price philippines
-
Key word:
-
solar panel 200w
-
Certificate:
-
CE, TUV, IEC, IOS
|
||||||
| Model Type | Power(W) | Vmp(V) | Imp(A) | Voc(V) | Isc(A) | |
| AS190S9-40 | 190 | 21.7 | 8.76 | 26.9 | 9.23 | |
| AS195S9-40 | 195 | 21.9 | 8.90 | 27.1 | 9.34 | |
| AS200S9-40 | 200 | 22.1 |
9.05 |
27.3 | 9.45 | |
| AS205S9-40 | 205 | 22.3 | 9.19 | 27.5 | 9.56 | |
| AS210S9-40 | 210 | 22.5 | 9.33 | 27.7 | 9.72 | |
| Standard test conditions:measured values(atmosphiric mass AM.5,irradiance 1000W/m2,battery temperature 25℃) | ||||||
| Mechanical P arameter (AS230M~260M) | ||||||
| Dimension | 1110*880*30mm | |||||
| Weight | 10kg | |||||
| Cell | 40 cells mono solar cell | |||||
| Junction Box | Protection class IP67/IP68,with bypass diodes | |||||
| Cable | 4mm² Solar cable, 90cm length | |||||
| Connector | Compatible | |||||
| Temperature rating | ||||||
| Rated battery operating temperature | 45±2℃ | |||||
| Maximum power temperature coefficient | -0.4%/℃ | |||||
| Open circuit voltage temperature coefficient | -0.29%/℃ | |||||
| Short circuit current temperature coefficient | -0.05%/℃ | |||||
| Limit parameter | ||||||
| Operating temperature | -40-+85℃ | |||||
| Maximum system voltage | 1000/1500VDC | |||||
| Maximum fuse rated current | 15A | |||||
| Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | ||
| FOB | |||||
| CFR(C&F) | 30% T/T in advance, paid the balance against copy of B/L | ||||
| CIF | |||||
| L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
| West Union | Amount lower than 5000usd | ||||
| Delivery Time | 7-10 working days after receiving payment (should be decided according to quantity) | ||||
