Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Sunmo
-
Model Number:
-
SMC-01
-
Warranty:
-
12 Months
-
product name:
-
tire service tools tire shop tire changer and balancer combo
-
tire changer inside clamp:
-
12-24"
-
tire changer outside clamp:
-
10-22"
-
wheel balancer rim diameter:
-
12-24"
-
wheel balancer max. wheel diameter:
-
980mm
-
wheel balancer max. wheel width:
-
4-15"
-
tire changer max. wheel diameter:
-
1050mm
-
tire changer wheel width:
-
4-13"
-
tire changer voltage:
-
110V/220V/380V
-
Certification:
-
CE
Quick Details
-
Motor Power:
-
0.75/1.1KW
-
Operating Pressure:
-
8-10Bar
-
Power Supply:
-
110V/220V/380V
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Sunmo
-
Model Number:
-
SMC-01
-
Warranty:
-
12 Months
-
product name:
-
tire service tools tire shop tire changer and balancer combo
-
tire changer inside clamp:
-
12-24"
-
tire changer outside clamp:
-
10-22"
-
wheel balancer rim diameter:
-
12-24"
-
wheel balancer max. wheel diameter:
-
980mm
-
wheel balancer max. wheel width:
-
4-15"
-
tire changer max. wheel diameter:
-
1050mm
-
tire changer wheel width:
-
4-13"
-
tire changer voltage:
-
110V/220V/380V
-
Certification:
-
CE
|
Wheel Alignment Specification
|
|
|
||
|
Item
|
Accuracy Range
|
Measurement Range
|
||
|
Total Toe
|
±0.01°
|
±40°
|
||
|
Camber
|
±0.01°
|
±45°
|
||
|
Kingpin Caster Angle
|
±0.02°
|
±45°
|
||
|
Kingpin Inclination Angle
|
±0.02°
|
±45°
|
||
|
Thrust Angle
|
±0.01°
|
±40°
|
||
|
Set Back
|
±0.01°
|
±40°
|
||
|
Turn In & Turn Out
|
±0.02°
|
±50°
|
||
|
Track Width
|
±2mm
|
1219~2438mm
|
||
|
Wheelbase Width
|
±2mm
|
2006~4572mm
|
||
|
Tire Changer
|
|
Wheel Balancer
|
|
||
|
External Rim Size
|
12"-22"
|
Rim Diameter
|
12"-24"
|
||
|
Internal Rim Size
|
12"-24"
|
Max. Tire Diameter
|
38.5"(980mm)
|
||
|
Max. Wheel Diameter
|
44.88"(1140mm)
|
Tire Width
|
15"
|
||
|
Tire Width
|
4"-13"(101-330mm)
|
Max.Tire Weight
|
70kg(154lbs)
|
||
|
Bead Breaker Force
|
2500kgs(5,500lbs)
|
Rotation Speed
|
180rpm
|
||
|
Working Pressure
|
8-10bar
|
Balance
|
7 s
|
||
|
Motor Power
|
1.1kw
|
Motor Power
|
0.25kw
|
||
|
Power Supply
|
110V/120V/220V/240V
|
Power Supply
|
110V/120V/220V/240V
|
||
|
Machine Size
|
1100X1200X1800mm
|
Machine Size
|
1080X550X920mm
|
||
|
Packing Size
|
1120X900X1000mm
|
Packing Size
|
1100X800X1100mm
|
||
|
N.W/G.W
|
225kg/260kg(496lb/573lb)
|
N.W/G.W
|
98kg/125kg(216lb/275.6lb)
|
||
