Quick Details
-
Voltage:
-
380
-
Power:
-
97kW/2300r/min
-
Dimension(L*W*H):
-
7260*3000*3000
-
Weight:
-
15000 kg
-
Maximum side paving height:
-
1800mm
-
Maximum paving width:
-
3000mm
-
Paving speed:
-
0~10m/min
-
Travel speed:
-
0~28m/min
-
Engine model:
-
QSB3.9-C130-30
-
Rated power/speed:
-
97kW/2300r/min
-
Diesel tank capacity:
-
360L
-
Climbing capacity:
-
≥ 25%
-
Vibrating rod interface:
-
8
-
Vibrating rod frequency:
-
0~200Hz
Quick Details
-
Marketing Type:
-
New Product 2022
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
new curber
-
Voltage:
-
380
-
Power:
-
97kW/2300r/min
-
Dimension(L*W*H):
-
7260*3000*3000
-
Weight:
-
15000 kg
-
Maximum side paving height:
-
1800mm
-
Maximum paving width:
-
3000mm
-
Paving speed:
-
0~10m/min
-
Travel speed:
-
0~28m/min
-
Engine model:
-
QSB3.9-C130-30
-
Rated power/speed:
-
97kW/2300r/min
-
Diesel tank capacity:
-
360L
-
Climbing capacity:
-
≥ 25%
-
Vibrating rod interface:
-
8
-
Vibrating rod frequency:
-
0~200Hz
Product Overview
NC1800 concrete slip form paver
NC1800 multifunctional slipform paver is a multi-purpose cement concrete construction equipment independently developed by our company. It can achieve various mold configuration modes, and is widely used in the construction fields of road drainage ditches, drainage channels, curbs, shoulder stones, concrete guardrails, cement concrete structures and farmland water conservancy ditches, replacing the traditional process and significantly improving the construction quality and speed of cement concrete structures.
The machine has a large power reserve, full electronic control, full hydraulic power drive, proportional control, three-track walking, and is equipped with automatic steering and automatic leveling control system. It can complete the vibration, paving, extrusion and other technological processes of cement concrete structures at one time.
Product Specifications
|
No
|
Item
|
Item
|
Data
|
|
|
1
|
Basic performance parameters
|
Maximum side paving height
|
1800mm
|
|
|
|
|
Maximum paving width
|
3000mm
|
|
|
|
|
Paving speed
|
0~15m/min
|
|
|
|
|
Travel speed
|
0~28m/min
|
|
|
2
|
Powertrain
|
Engine model
|
QSB3.9-C130-30 (china)
|
|
|
|
|
Rated power/speed
|
97kW/2300r/min
|
|
|
|
|
Diesel tank capacity
|
360L
|
|
|
3
|
Walking system
|
Three tracks (front two and rear one), hydraulic independent drive, proportional control two-speed motor, large speed ratio
planetary gear reducer, paving speed closed-loop control, PID adjustment |
|
|
|
|
|
Track width
|
300mm
|
|
|
|
|
Track length
|
1600mm
|
|
|
|
|
Climbing capacity
|
≥ 25%
|
|
|
4
|
Outrigger steering lifting device
|
Three-track steering device is equipped with displacement sensor, precise proportional control, crab walking, cooperative
steering, and small turning radius; Outrigger lifting hydraulic proportional control |
|
|
|
|
|
Minimum turning radius
|
4600mm
|
|
|
|
|
Outrigger hydraulic lifting stroke
|
1120mm
|
|
|
|
|
Outrigger mechanical adjustment stroke
|
500mm
|
|
|
5
|
Outrigger swing sliding device
|
Hydraulic adjustment right front outrigger internal and external swing, left front outrigger extension, rear outrigger extension
|
|
|
|
|
|
The inner and outer swing amplitude of the right front outrigger
|
680mm
|
|
|
|
|
Telescopic stroke of left front outrigger
|
1100mm
|
|
|
|
|
Telescopic stroke of rear outrigger
|
710mm
|
|
|
6
|
Hydraulic system
|
Load sensitive multi-pump hydraulic system, proportional control walking, outrigger steering lifting, vibrating rod
|
|
|
|
|
|
Hydraulic oil cooling
|
Large radiator, forced air cooling
|
|
|
|
|
Hydraulic oil filter
|
Equipped with oil suction filter and filtering accuracy of 10 μ m Return oil filter
|
|
|
|
|
Hydraulic tank capacity
|
410L
|
|
|
6
|
Electrical control system
|
Humanized design of operation console, human-computer interactive control screen, clear graphical identification symbols, 24V
voltage power supply system Configure two longitudinal slope sensors, one transverse slope sensor and two steering sensorsThe longitudinal slope, cross slope and steering adopt electronic automatic control, and the sensor and controller adopt CAN bus communication Equipped with Internet of Things platform, construction management and monitoring system, and optional remote control device |
|
|
|
7
|
Auger conveyor
|
Twister speed
|
0~70r/min
|
|
|
|
|
The size of the auger feeding device long,
|
3700mm
|
|
|
|
|
The blade diameter
|
340mm
|
|
|
8
|
Vibrating compaction system
|
Hydraulic vibrator interface
|
8
|
|
|
|
|
Vibrating rod frequency
|
0~200Hz
|
|
|
9
|
High-pressure flushing device
|
Hydraulic driven high pressure ceramic plunger pump
|
|
|
|
|
|
water tank capacity
|
310L
|
|
|
10
|
Mold and mold fixture
|
Hydraulic horizontal stroke of mold fixture
|
1000mm
|
|
|
|
|
Hydraulic vertical stroke of mold fixture (double oil cylinder)
|
360mm
|
|
|
|
|
Mechanical vertical stroke of mold fixture
|
240mm
|
|
|
11
|
Overall dimension and weight (transportation status)
|
Transport dimension (long × wide × High)
|
7260*3000*3000mm
|
|
|
|
|
Operating Weight
|
15500Kg
|
|
