Quick Details
-
Place of Origin:
-
Anhui, China
-
Product Name:
-
Repeater
-
Frequency Range Uplink:
-
880-915MHz/1710-1785MHz
-
Frequency Range Downlink:
-
925-960MHz/1805-1880MHz
-
Application:
-
INDOOR OUTDOOR IP65
-
Maximum Output Power(Customized):
-
Uplink:30±2dBm;Downlink:43±2dBm
-
Maximum Gain:
-
≥ 90dB
-
VSWR:
-
≤ 1.5
-
Gain Adjustment Range:
-
1~31 dB @ step of 1 dB
-
In-band Ripple:
-
≤ ±3dB
-
Noise Figure:
-
≤ 6dB
Quick Details
-
Brand Name:
-
Maniron
-
Model Number:
-
MN9A43B2
-
Type:
-
Repeater
-
Place of Origin:
-
Anhui, China
-
Product Name:
-
Repeater
-
Frequency Range Uplink:
-
880-915MHz/1710-1785MHz
-
Frequency Range Downlink:
-
925-960MHz/1805-1880MHz
-
Application:
-
INDOOR OUTDOOR IP65
-
Maximum Output Power(Customized):
-
Uplink:30±2dBm;Downlink:43±2dBm
-
Maximum Gain:
-
≥ 90dB
-
VSWR:
-
≤ 1.5
-
Gain Adjustment Range:
-
1~31 dB @ step of 1 dB
-
In-band Ripple:
-
≤ ±3dB
-
Noise Figure:
-
≤ 6dB
|
System
|
GSM900/LTE1800
|
|
Frequency Uplink
|
880-915MHz/1710-1785MHz
|
|
Frequency Downlink
|
925-960MHz/1805-1880MHz
|
|
VSWR
|
≤1.5
|
|
Maximum Output Power(Customized)
|
Uplink:30±2dBm
Downlink:43±2dBm
|
|
Gain Adjustment Range
|
1~31 dB @ step of 1 dB
|
|
Maximum Gain
|
≥ 90dB
|
|
Noise Figure
|
≤ 6dB
|
Our Services
1. Professional skills support.
2. OEM services is available.
3. 24 hours you can contact our salesman and engineer.
4. We will try our best to provide support whatever you need and we can do.
NOTE:All the specifications can be changed as customer's requirment. Our company has a variety of products to choose.
