Quick Details
-
Model Number:
-
Hanz Nb sheet
-
Shape:
-
plate, sheet, foil
-
Material:
-
niobium
-
Chemical Composition:
-
niobium alloy
-
Product name:
-
Niobium sheet
-
Standard:
-
ASTM B393
-
Purity:
-
99.95% min
-
Model number:
-
R04200, R04210, R04251, R04261
-
Color:
-
Silver Gray
-
Melting Point:
-
2468℃
-
Boiling point:
-
4742℃
-
Density:
-
8.57g/cm3
-
Feature:
-
low steam pressure
Quick Details
-
Application:
-
Metallurgy, Industrial, Electronic, Medical,etc, Industry
-
Place of Origin:
-
Shaanxi
-
Brand Name:
-
Baoji Hanz
-
Model Number:
-
Hanz Nb sheet
-
Shape:
-
plate, sheet, foil
-
Material:
-
niobium
-
Chemical Composition:
-
niobium alloy
-
Product name:
-
Niobium sheet
-
Standard:
-
ASTM B393
-
Purity:
-
99.95% min
-
Model number:
-
R04200, R04210, R04251, R04261
-
Color:
-
Silver Gray
-
Melting Point:
-
2468℃
-
Boiling point:
-
4742℃
-
Density:
-
8.57g/cm3
-
Feature:
-
low steam pressure
Factory supply niobium c103 alloy sheet for aerospace aviation
Factory supply niobium c103 alloy sheet for aerospace aviation
Specification
| Item | Factory supply niobium c103 alloy sheet for aerospace aviation |
| Standard | ASTM B393 |
| Density | 8.57g/cm3 |
| Purity | ≥99.95% |
| Melting point | 2468℃ |
| Grade | R04200, R04210, R04251, R04261 |
| Surface | polishing, grinding |
| Technique | sintered, rolled, forged |
| Feature | High temperature resistance, corrosion resistance |
| Application | Superconducting industry, Aerospace aviation, Chmeical Industry, Mechanical |
Dimensions
| Grade | Dimensions | Type | ||
| Thickness/mm | Width/mm | Length/mm | ||
|
R04200 R04210 R04251 R04261 |
0.05 | 300 | >300 | Foil |
| >0.1~0.5 | 50~450 | 100~10000 |
Sheet
Plate |
|
| >0.5~0.8 | 50~450 | 50~2000 | ||
| >0.8~2.0 | 50~1500 | 50~2000 | Plate | |
| >2.0~6.0 | 50~1500 | 50~1500 | ||
| >6.0 | 50~650 | 50~1500 | ||
Chemical Composition
| Grade | R04200 | R04210 | R04251 | R04261 | |
| Nb Content% | Remain | Remain | Remain | Remain | |
| Impurity content (%)≤ | Fe | 0.005 | 0.03 | 0.01 | 0.04 |
| Ni | 0.005 | 0.01 | 0.005 | 0.01 | |
| W | 0.03 | 0.05 | 0.05 | 0.05 | |
| Si | 0.005 | 0.02 | 0.01 | 0.03 | |
| Mo | 0.01 | 0.05 | 0.02 | 0.05 | |
| Cr | 0.002 | 0.01 | 0.005 | 0.01 | |
| Ti | 0.002 | 0.005 | 0.005 | 0.01 | |
| Ta | 0.01 | 0.25 | -- | -- | |
| O | 0.015 | 0.025 | 0.030 | 0.060 | |
| C | 0.01 | 0.02 | 0.03 | 0.05 | |
| H | 0.001 | 0.005 | 0.002 | 0.005 | |
| N | 0.015 | 0.05 | 0.035 | 0.05 | |
Factory supply niobium c103 alloy sheet for aerospace aviation
|
Features
|
|
Applications
|
Factory supply niobium c103 alloy sheet for aerospace aviation
Packaging:
- Wrapped with water-proof paper
- Surrounded with foam and then put into plywood box
- Sealed and fixed
- As customer's requirements packing
Shipping:
Various Mode of Transportation for you:
- Air transportation
- Sea transportation
- By Express mail: DHL, FedEX, UPS, EMS, SF-Express, etc
After we send the tantalum tube, we will send you the tracking number to check in time, and also we will keep tracking the order until you received successfully.
