Quick Details
-
Brand Name:
-
Sunnal
-
Model Number:
-
SNA-PWM-KDY
-
Work Time (h):
-
50000
-
Max PV Power:
-
390-5200W
-
Max PV Voltage:
-
150Vdc
-
Certificate:
-
CE,ROHS
-
Warranty:
-
3 YEAR
-
Battery type:
-
Lead-acid/Lithium/LiFePO4 Battery
-
MPPT efficiency:
-
99.9%
-
Display:
-
LCD
-
Weight:
-
1.2KG
-
Charge Current:
-
10a 20a 30a 40a
-
Altitude:
-
≤3000m
-
Supply Ability:
-
100000 Set/Sets per Month
-
Working Temperature:
-
-35℃~+45℃
Quick Details
-
Type:
-
PWM
-
Application:
-
Charger Controller, Water Heater Controller, Solar Working Station, Lighting Controller, Thermal Controller, Voltage Controller, Solar System Controller
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Sunnal
-
Model Number:
-
SNA-PWM-KDY
-
Work Time (h):
-
50000
-
Max PV Power:
-
390-5200W
-
Max PV Voltage:
-
150Vdc
-
Certificate:
-
CE,ROHS
-
Warranty:
-
3 YEAR
-
Battery type:
-
Lead-acid/Lithium/LiFePO4 Battery
-
MPPT efficiency:
-
99.9%
-
Display:
-
LCD
-
Weight:
-
1.2KG
-
Charge Current:
-
10a 20a 30a 40a
-
Altitude:
-
≤3000m
-
Supply Ability:
-
100000 Set/Sets per Month
-
Working Temperature:
-
-35℃~+45℃
Products Description
|
Charging Current
|
10A
|
20A
|
30A
|
40A
|
50A
|
60A
|
|||||
|
Discharging Current
|
10A
|
20A
|
30A
|
40A
|
50A
|
60A
|
|||||
|
Battery Voltage
|
12V 24V Auto
|
|
|
|
|
|
|||||
|
Max Solar input
|
48V(for 24V battery) 24V(for 12V battery)
|
|
|
|
|
|
|||||
|
Equalization
|
14.4V(Sealed) 14.2V(Gel) 14.6V(Flood)
|
|
|
|
|
|
|||||
|
Float charge
|
13.7V(defaul,adjustable)
|
|
|
|
|
|
|||||
|
Discharge stop
|
10.7V(defaul,adjustable)
|
|
|
|
|
|
|||||
|
Discharge reconnect
|
12.6V(defaul,adjustable)
|
|
|
|
|
|
|||||
|
Charge reconnect
|
13V
|
|
|
|
|
|
|||||
|
Voltage of open light
|
Solar Panel 8V(Light lights delay)
|
|
|
|
|
|
|||||
|
Voltage of close light
|
Solar Panel 8V(Light off delay)
|
|
|
|
|
|
|||||
|
USB output
|
5V/3A
|
|
|
|
|
|
|||||
|
Self-consume
|
<10mA
|
|
|
|
|
|
|||||
|
Operating temperature
|
-35°C~+60°C
|
|
|
|
|
|
|||||
Specification
Features :
1.Build-in industrial micro controller.
2.Big LCD display,all adjustable parameter.
3.Fully 3-stage PWM charge management.
4.Build-in short-circuit protection,open-circuit protection,reverse protection,over-load protection.
5.Dual USB output, the maximum current of 2.5A, to support Apple's mobile phone charging.
6.Dual mosfet Reverse current protection,low heat production.
1.Build-in industrial micro controller.
2.Big LCD display,all adjustable parameter.
3.Fully 3-stage PWM charge management.
4.Build-in short-circuit protection,open-circuit protection,reverse protection,over-load protection.
5.Dual USB output, the maximum current of 2.5A, to support Apple's mobile phone charging.
6.Dual mosfet Reverse current protection,low heat production.
