Quick Details
-
Model Number:
-
NMC PLB-D5
-
Battery Size:
-
Coin cell ,cylinder cell,pouch cell
-
Place of Origin:
-
Shandong, China
-
Weight:
-
25kg per package
-
pH:
-
11.5
-
Color:
-
Black
-
1st efficiency:
-
89.6%
-
D50:
-
5-8 um
-
Moisture:
-
350ppm
-
BET Surface Area:
-
0.35m2/g
-
Tap Density:
-
2.4 g/cm3
-
1st Discharge Capacity:
-
181.5 mAh/g
-
Product name:
-
LiNiMnCoO2 NMC PLB-D5
Quick Details
-
Anode Material:
-
Other
-
Application:
-
Lithium ion battery
-
Brand Name:
-
Gelon
-
Model Number:
-
NMC PLB-D5
-
Battery Size:
-
Coin cell ,cylinder cell,pouch cell
-
Place of Origin:
-
Shandong, China
-
Weight:
-
25kg per package
-
pH:
-
11.5
-
Color:
-
Black
-
1st efficiency:
-
89.6%
-
D50:
-
5-8 um
-
Moisture:
-
350ppm
-
BET Surface Area:
-
0.35m2/g
-
Tap Density:
-
2.4 g/cm3
-
1st Discharge Capacity:
-
181.5 mAh/g
-
Product name:
-
LiNiMnCoO2 NMC PLB-D5
High Voltage Lithium Nickel Manganese Cobalt Oxide LiNiMnCoO2 NMC PLB-D5
I.Specification
|
Item |
Unit |
Standard |
Typical |
|
|
Chemical Compositions |
Li |
% |
7.2±0.6 |
7.1 |
|
Ni+Mn+Co |
% |
59.0±1.0 |
58.50 |
|
|
Impurity |
Fe |
ppm |
≤100 |
45 |
|
Na |
ppm |
≤100 |
48 |
|
|
Cu |
ppm |
≤50 |
2 |
|
|
Particle Size Distribution |
D10 |
μm |
≥5.000 |
10.8 |
|
D50 |
μm |
11.5 ± 1.5 |
11.6 |
|
|
D90 |
μm |
≤25.0 |
19.6 |
|
|
D max |
μm |
≤45.00 |
28.5 |
|
|
XRD Lattice Type |
/ |
/ |
/ |
|
|
pH |
/ |
≤12.0 |
11.7 |
|
|
Moisture |
ppm |
≤500 |
350 |
|
|
BET Surface Area |
m 2 /g |
0.35±0.15 |
0.35 |
|
|
Tap Density |
g/cm 3 |
≥2.1 |
2.4 |
|
|
1 st Discharge Capacity (CR2032, 0.1/0.1C, 3.0 ~ 4.3V v.s. Li) |
mAh/g |
≥178.0 |
181.5 |
|
|
1 st efficiency |
% |
≥85.00 |
89.6 |
|
II.Paticle size distribution:
III.Coin cell charging and discharging curve:
The materials designed capacity is 162~168mAh/g(full cell,0.5C)
Suggest the recipe as followes:
T61A:SP:PVDF(HSV900)=95.2% : 2.5% : 2.3%
What We Can Supply:
1.)full set of
lithium battery materials
,including :
LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Alumimun foil,copper foils,battery separator,etc.
2.)full set of
lithium battery equipments
,for example:
Mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.
3.)full set of
lithium battery technology
:
We can design the laboratory and production line,according to customer's request.
