Quick Details
-
Welding Mode:
-
TIG MIG PLASMA or SAW
-
Welding Diameter:
-
500-8000mm
-
Dimensions:
-
3500*11500*2300mm
-
Use:
-
Tank automatic welding
-
Voltage:
-
380V or special
-
Weight (KG):
-
6000 KG
-
Product name:
-
Longitudinal seam welding machine
-
Welding Material:
-
carbon steel; stainless steel; aluminum
-
Welding Length:
-
≤2000mm
-
Welding diameter:
-
≤1100mm
-
Machine Type:
-
Welding Manipulator
-
Usage:
-
linear seam welding
-
Clamping Mode:
-
Pneumatic key type press
-
Control mode:
-
PLC
-
Welding wire feeder:
-
Yes
Quick Details
-
Marketing Type:
-
Hot Product 2023
-
Place of Origin:
-
China
-
Brand Name:
-
Wanda
-
Welding Mode:
-
TIG MIG PLASMA or SAW
-
Welding Diameter:
-
500-8000mm
-
Dimensions:
-
3500*11500*2300mm
-
Use:
-
Tank automatic welding
-
Voltage:
-
380V or special
-
Weight (KG):
-
6000 KG
-
Product name:
-
Longitudinal seam welding machine
-
Welding Material:
-
carbon steel; stainless steel; aluminum
-
Welding Length:
-
≤2000mm
-
Welding diameter:
-
≤1100mm
-
Machine Type:
-
Welding Manipulator
-
Usage:
-
linear seam welding
-
Clamping Mode:
-
Pneumatic key type press
-
Control mode:
-
PLC
-
Welding wire feeder:
-
Yes
Product Description
External longitudinal seam welding of medium and thin wall simplified. It can be equipped with TIG, MIG/MAG, PAW welding tooling. Suitable for the welding of carbon steel, stainless steel, aluminum and its alloy, titanium and its alloy and other materials. It can be used for welding of products such as food machinery, dyeing and finishing equipment, power switch busbar barrel, medical machinery, special chemical container, power pipeline, air conditioning machine shell, etc., and according to the specific situation of the workpiece, this kind of longitudinal seam fixture height and increase the safety protection device. The welding process is reliable and efficient, and the whole welding process is controlled by program.
|
Type
|
Small Type
|
|
|
Inner Type
|
|
|
||||
|
Model
|
WD-1500
|
WD-2000
|
WD-3000
|
WD-4000
|
WD-6000
|
WD-7500
|
||||
|
Single torch
Welding Length(mm) |
|
2000
|
3000
|
4200
|
6900
|
8400
|
||||
|
Double torch
Welding Length(mm) |
1500
|
1600
|
2600
|
3800
|
6100
|
7600
|
||||
|
Max clamping length(mm)
|
1590
|
2100
|
3075
|
4200
|
6900
|
8400
|
||||
|
Max
clamping diameter(outside weld mm) |
850
|
1100
|
1200
|
|
|
|
||||
|
Round Mandrel Mini clamping diameter（mm）
|
110
|
180
|
180
|
|
|
|
||||
|
Square Mandrel Mini clamping diameter
(outside weld mm) |
|
330
|
330
|
|
|
|
||||
|
Mini clamping length(outside weld mm)
|
|
2000
|
2000
|
1600
|
1600
|
1600
|
||||
|
Mini clamping thickness (mm)
|
0.4
|
1.0
|
1.0
|
1.5
|
1.5
|
1.5
|
||||
|
Max clamping thickness(mm)
|
3.0
|
12
|
12
|
12
|
12
|
12
|
||||
|
Shaft end bracket adjustment
|
10
|
10
|
10
|
10
|
10
|
10
|
||||
|
Trolley moving speed
|
60-1200
|
60-1200
|
60-1200
|
60-1200
|
60-1200
|
60-1200
|
||||
|
Max trolley moving distance(m/min)
|
1600
|
3000
|
4000
|
6300
|
9000
|
10750
|
||||
|
Dimension(mm)
|
2530*820*1600
|
3500*1150*2300
|
4900*1200*2400
|
7100*1200*1800
|
9100*1200*1800
|
11050*1200*2000
|
||||
Specification
