Quick Details
-
Core Components:
-
PCB
-
Brand Name:
-
klo power
-
Voltage:
-
12v
-
Power:
-
12K
-
Dimension(L*W*H):
-
48*46*27CM
-
Applicable Industries:
-
plating
-
Weight (KG):
-
30
-
Application:
-
electroplating
-
color:
-
gray blue
-
Type:
-
High Frequency Switch mode Rectifier
-
Efficiency:
-
90%
Quick Details
-
Place of Origin:
-
Shandong, China
-
Machine Type:
-
IGBT
-
Marketing Type:
-
Hot Product 2023
-
Core Components:
-
PCB
-
Brand Name:
-
klo power
-
Voltage:
-
12v
-
Power:
-
12K
-
Dimension(L*W*H):
-
48*46*27CM
-
Applicable Industries:
-
plating
-
Weight (KG):
-
30
-
Application:
-
electroplating
-
color:
-
gray blue
-
Type:
-
High Frequency Switch mode Rectifier
-
Efficiency:
-
90%
We are professional and creative manufacturer. Our reliable quality of rectifiers will definitely satisfy your requirements.
Advantage:
1) Small, light and high efficiency
2) High frequency pulse current output
3) Flexible use, simple operation
4) Complete protection function
5)extra function:0-5v,4-20ma,0-10v,rs485,PLC interface,timer,ampere hour meter,slow start,touch screen
Follow ISO 9001 quality standard,CE certificate
| high frequency 12v 1000 amp electroplating rectifier | |
| input voltage |
3 phase 380vac±10%,50hz or 3 phase 220VAC,415VAC,440VAC,480VAC,600VAC OEM |
| output voltage | 0-12v dc adjustable |
| output current | 0-1000a adjustable |
| output power | 12KW |
|
Adjustment range |
From 0-100 % continuously adjustable voltage and current |
|
Output conditioning method |
Switching mode, PWM Pulse control |
|
Machine efficiency |
≥9 0 % |
|
Constant voltage control accuracy |
Within 1.0%of rated output voltage |
|
Constant current control accuracy |
Within 1.0%of rated output current |
|
Insulation resistance |
5MΩ or more |
|
Cooling system |
Forced air cooling water cooled can be choosed |
|
Operating temperature |
-15+45℃(overheating self-protect) |
|
Ambient temperature |
-30-65℃ |
|
Relative humidity |
30-85% |
|
protection |
Over heating,over current,over voltage,lack phase,over load,input over/low voltage |
|
Control mode |
6 meter cables Remote control box ,front panel control,PLC interface,touch screen can be OEM made |
