Quick Details
-
Drilling Speed:
-
6 speed
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
XR-450
-
Model Number:
-
XR-5168E
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
550*205*205mm
-
Power (kW):
-
680W
-
Weight (KG):
-
9.8 KG
-
Marketing Type:
-
New Product 2021
-
Product Name:
-
Bench Drill
-
Series:
-
bench drilling machine
-
Frequency:
-
50Hz/60Hz
-
Power:
-
680W
-
Stroke Length:
-
60mm
-
Working Radius:
-
150mm
-
Clamping Capacity:
-
1-13mm
-
No-Load Speed:
-
1100r/min, 2500r/min, 4500r/min
-
Application:
-
Can be widely used metal, wood boards, plastic materials, etc.
-
Keyword:
-
Bench Drilling Press Machine
Quick Details
-
type:
-
Bench Drilling Machine
-
Max. Drilling Dia. (mm):
-
13
-
Range of Spindle Speed(r.p.m):
-
1 - 4500 r.p.m
-
Drilling Speed:
-
6 speed
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
XR-450
-
Model Number:
-
XR-5168E
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
550*205*205mm
-
Power (kW):
-
680W
-
Weight (KG):
-
9.8 KG
-
Marketing Type:
-
New Product 2021
-
Product Name:
-
Bench Drill
-
Series:
-
bench drilling machine
-
Frequency:
-
50Hz/60Hz
-
Power:
-
680W
-
Stroke Length:
-
60mm
-
Working Radius:
-
150mm
-
Clamping Capacity:
-
1-13mm
-
No-Load Speed:
-
1100r/min, 2500r/min, 4500r/min
-
Application:
-
Can be widely used metal, wood boards, plastic materials, etc.
-
Keyword:
-
Bench Drilling Press Machine
Hot Sale Low Noise Spindle Travel 60mm CNC Mini Bench Drilling Machine High Quality Small Table Top Drill Press Milling Machine
Products Description
| Product Name | Bench Drill |
| Voltage | 220V |
| No-load Speed | 0-4500R/MIN |
| Frequency | 50-60Hz |
| Power | 680W |
| Stroke Length | 60mm |
| Working Radius | 150mm |
| Clamping Capacity | 1-13mm |
| Application | Can be widely used metal, wood boards, plastic materials, etc. |
| Feature |
1.Industrial High Precision Multipurpose Automatic Bench Drilling Machine.
2.Gear drive without belt design,Power strong. 3.Power-off switch for added safety. 4.Can be widely used model, wood boards, plastic sheeting, aluminum, composite panels, resin panels, thin metal, circuit boards, precision machining of hard materials and other non-specific drilling. 5.Is hardware processing, mold making, document binding, electronic manufacturers, scientific experiments and other units of the ideal tool. |
| Power | 480W |
| Clamping Capacity | 1-10mm |
| Working Radius | 110mm |
| Rotating Speed | 11000r/min |
| Stroke Length | 40mm |
| Drilling Capacity | Iron Φ7mm wood Φ25mm |
| Power | 680W |
| Clamping Capacity | 1-13mm |
| Working Radius | 150mm |
| Rotating Speed | 1100r / 2500r / 4500r / min |
| Stroke Length | 60mm |
| Drilling Capacity | Iron Φ8mm wood Φ30mm |
| Power | 710W |
| Clamping Capacity | 5-13mm |
| Working Radius |
110mm |
| Rotating Speed | 0-2800r/min |
| Stroke Length | 60mm |
| Drilling Capacity | Iron Φ8mm wood Φ30mm |
| Power | 800W |
| Clamping Capacity | 1.5-13mm |
| Working Radius | 125mm |
| Rotating Speed | 200-2500r/min |
| Stroke Length | 90mm |
| Drilling Capacity | Iron Φ8mm wood Φ30mm |
| Power | 880W |
| Clamping Capacity | 1.5-13mm |
| Working Radius | 140mm |
| Rotating Speed | 0-2500r/min |
| Stroke Length | 60mm |
| Drilling Capacity | Iron Φ13mm wood Φ35mm |
| Power | 1050W |
| Clamping Capacity | 3-16mm |
| Working Radius | 140mm |
| Rotating Speed | 0-800r/min |
| Stroke Length | 60mm |
| Drilling Capacity | Iron Φ13mm wood Φ35mm |
| Power | 340W |
| Clamping Capacity | 1-10mm |
| Working Radius | 110mm |
| Rotating Speed | 0-16000r/min |
| Stroke Length | 25mm |
| Drilling Capacity | Wood Φ25mm |
| Power | 150W |
| Clamping Capacity | 0.6-6.5mm |
| Working Radius | 110mm |
| Rotating Speed | 0-16000r/min |
| Stroke Length | 25mm |
| Drilling Capacity | Wood Φ25mm |
| Product Name | Heavy Duty Vise |
| X Axistravel | 80mm |
| Y Axistravel | 67mm |
| Base Hole Distance | 100mm |
| Maximum Clamping Thickness | 75mm |
| Product Name | Cross Slide Vise |
| X Axistravel | 200mm |
| Y Axistravel | 50mm |
| Base Hole Distance | 100mm |
| Maximum Clamping Thickness | 280mm |
