Quick Details
-
Printer:
-
58mm thermal printer
-
Smart card reader:
-
NFC
-
Wireless and Communication:
-
2G/3G/4G, Wi-Fi, Blue tooth
-
Battery:
-
2200mAh
-
Main screen:
-
10.1" Touch screen
-
Colour:
-
Black
-
Main board:
-
Baytrial /1037/I3/I5 mother board
-
Touch Screen:
-
10 Points Capactive Touch
-
Resolution:
-
1024*600 Pixel
-
IC card reader:
-
Optional
-
Operation System:
-
Android 11
-
Hard Disk Capacity:
-
2GB/4GB/8GB/16GB optional
Quick Details
-
Brand Name:
-
TOUSEI
-
CPU:
-
1.8ghz RK3566 ARM 64-bit 4-core A55 processor
-
Place of Origin:
-
Guangdong, China
-
Printer:
-
58mm thermal printer
-
Smart card reader:
-
NFC
-
Wireless and Communication:
-
2G/3G/4G, Wi-Fi, Blue tooth
-
Battery:
-
2200mAh
-
Main screen:
-
10.1" Touch screen
-
Colour:
-
Black
-
Main board:
-
Baytrial /1037/I3/I5 mother board
-
Touch Screen:
-
10 Points Capactive Touch
-
Resolution:
-
1024*600 Pixel
-
IC card reader:
-
Optional
-
Operation System:
-
Android 11
-
Hard Disk Capacity:
-
2GB/4GB/8GB/16GB optional
|
Operation System
|
Android 11
|
|
2D code decoding
|
with built-in 2D code decoding software
|
|
CPU
|
1.8ghz RK3566 ARM 64-bit 4-core A55 processor
|
|
Memory
|
DDR4 2GB cache chip EMMC 8GB expandable to 64GB
|
|
LCD panel
|
10.1 inch RGB TFT,1024*600 pixel, Aspect ratio:16:9 G+F capacitive multi-point touch, explosion-proof
|
|
2D code camera
|
640X480 pixel .(gray scale) CMOS camera 1.3 megapixel +LEB
backlight brightness is adjustable
Camera range 55X45MM Lens fixed focal length |
|
NFC card reader (optional)
|
Contactless PHIL IPS MIFARE STANDARD ISO14443, S010536 and IS07816
|
|
IC card reader
|
Contact IC card, support bank card and social security card
|
|
Commucation module
|
4G Full netcom module supports China Unicom, China Mobile and China Telecom 4G WIFI module: standard ---EEE802.11b/ G/N Compatible
with WAPI (optional)Ethernet interface (RJ45) Supports common protocols such as TCP/IP and HTTP |
|
Backup battery
|
Rechargeable 18650 battery 7.4V 2000/5000/20000mah, overvoltage, low current protection,
|
|
ldentification card
|
Ministry of Public Security standard ID card reader module
|
|
Printer
|
High speed thermal printer,
Paper width: 58mm, printing speed: upto 50mm/s can print text, image, bar code with setting size and font |
|
Antenna
|
Built-in high gain antenna
|
|
Multi-media function
|
High effient DSP processing, music,support mp3, wma and etc,support lyric display line by line or full display Video, support avi,
rm,3gp and etc, upto 1080p Picture, jpeg, jpg, bmp, gif, jf support upto 8000*8000 pixel |
|
External interface
|
USB 2.0 Host x 1, USB device x 1,mini USB OTG x1
|
|
|
Rs232 serial port x 1 (standard DB 9)
|
|
|
TF card slot x 1 (support upto 32GB)
|
|
|
Power switch X 1
|
|
|
DC power input socket(9V, 4A) x1
|
|
|
RJ11 cash drawer port(12V) X 1
|
|
|
RJ11 Password keypad X 1
|
|
|
Telephone, 3G internet phone or wired normal phone
|
|
|
Earphone port x 1, Microphone port x 1
|
|
|
2xPSAM card+2xSIM card(1standby) or 3xPSAM+1 xSIM card
|
|
Accessories
|
DC power adaptor,input 100-240V, output, 9V, 4A Built-in high gain antenna
|
|
Drop standard
|
1.5 meter drop on concrete floor
|
|
Humidty
|
95% without sticky
|
|
ESD protection
|
12kv
|
|
SIM card
|
Meet all carrier standards (China Mobile/China Unicom/China Telecom)
|
Shenzhen Tousei Technology Co., Ltd was established in 2011.We are a leading provider, who specialized in designing, producing and selling the intelligent terminal equipment, which covers android smart terminal, PDA, mobile printer and handheld barcode scanner. Electronics Factory covers an area of around 8, 000 square meters, it has a perfect production facilities and advanced research and development test equipment: Horizontal injection press, Vertical injection press, Welding machine, Ultrasonic sewing machine, Pad printing machine, Constant temperature and Humidity test chamber, Swing tester, Integrated electroacoustic, instrument, Salt spray test machine, Key life test insturment, and so on. The factory include four production workshop (The injection molding workshop, The finished product assembly workshop, Environment-protecting workshop and Oil pad printing workshop), a comprehensive research and development laboratoryand automatic assembly line. Now, there are more than 300 skilled employees, including more than 30 QCstaffs and 6 R&D engineers, daily output reaches up to 60, 000PCS. We manufacture 70% of electronic components in our own well equipped factory. So we can ensure stable product performance, high product quality, lower product costs and fast delivery. In addition, the factory conduct a perfect quality controlsystem so as to ensure that the qualification rate for the finished products is no less than than 98%.With over 9 years of experience and the strong R&D support, we fully possess the capacity to handle OEM and ODM orders, including packaging and ID design. 3D design. Prototype sample making.development. Painting. Screen printing. Assembly. Now, we have been successfully cooperating with customers from Europe. Asia. Japan. America and other 87 countries and regions. We are looking forward to establishing long term business relationships with you.
FAQ
1. Do you have the items in stock?
The most of products are in stock.We can send the goods out within 3days after payment received. For the goods are out of stock,production time is about 7-10 days.
2. Do you offer other relevant items?
Yes we do.We are offering PDA data collector,POS system, Thermal printer, core board design and production and so on.
3. If the goods are damaged badly,who is responsible for it?
We will be responsible for the damaged goods when it is damaged during transport,and we can exchange the new goods for you.
4. Can you make OEM or ODM for products?
OEM and ODM products is available for customer,as long as customer meet the MOQ. Also we have engineers for logo and products design for customers.
5. What about delivery time?
Samples and small order within 5 working days; bulk order delivery kindly check with seller.
6,What about MOQ?
We can accept sample order firstly, Without MOQ.
7. What warranty and after-sale service do you offer?
Warranty: 12 month for free if the issue caused by non-artificial damages.
|
